GUIFrame UDF - Melba23 version - 19 May 14

[Mikeman27294]

Windows 7 Home Premium 64 bit.

[Melba23]

Mikeman27294,

The UDF should be x64 compliant - did this problem occur after you moved to x64?

M23

[spudw2k]

Just tested this myself last night on Windows 7 x64.

[Mikeman27294]

No, I have used it before on an x64 system. I am running it on the 32 bit autoit executable though.

[Melba23]

Mikeman27294,

Could you please try with AutoIt3_x64.exe. If you are mixing x86 and x64 I would hazard a guess that the subclassing is not working correctly and so you are not substituting the UDF WndProcs for the Windows versions.

M23

[Mikeman27294]

Yes, running it under the 64 bit executable worked. Does that mean that it is calling 64 bit DLLs but running under 32 bit and so the DLL is incompatible?

Edited January 19, 2012 by Mikeman27294

[wraithdu]

@Melba23

I think this is happening because in your subclassing function you are testing @OSArch, the bitness of the OS, instead of the bitness of AutoIt. Try replacing that with @AutoItX64 and see if it works on Win x64 as a 32-bit app.

[Melba23]

wraithdu,

Sounds reasonable to me - do you have an x64 machine to test this version of the UDF with your suggested change?

expandcollapse popup

#include-once
; #INDEX# ============================================================================================================
; Title .........: GUIFrame
; AutoIt Version : 3.3 +
; Language ......: English
; Description ...: Splits a GUI into slideable and resizable 2 part frames which can be further split if required
; Remarks .......: - The UDF uses OnAutoItExitRegister to call _GUIFrame_Exit to delete subclassed separator bars
;                    using the UDF created WndProc and to release the Callback on exit
;                  - If the script already has a WM_SIZE handler then do NOT use _GUIFrame_ResizeReg,
;                    but call _GUIFrame_SIZE_Handler from within the existing handler
; Author ........: Original UDF by Kip
; Modified ......; This version by Melba23 - using x64 compatible code drawn from Yashied's WinAPIEx library
; ====================================================================================================================

;#AutoIt3Wrapper_au3check_parameters=-d -w 1 -w 2 -w 3 -w 4 -w 5 -w 6

; #INCLUDES# =========================================================================================================
#include <WinAPI.au3>

; #GLOBAL VARIABLES# =================================================================================================

; Array to hold handles for each frame set
Global $aGF_HandleIndex[1][7]
; [0][0] = 0 ; Count of frames      [0][1] = Move registered flag
; [n][0] = Parent GUI handle        [n][4] = Original GUI handle
; [n][1] = First frame handle       [n][5] = Indices of first frame internal frames
; [n][2] = Second frame handle      [n][6] = Indices of second frame internal frames
; [n][3] = Separator bar handle

; Array to hold sizing percentages for each frame set
Global $aGF_SizingIndex[1][6]
; [n][0] = First frame min      [n][2] = X coord    [n][4] = Width
; [n][1] = Second frame min     [n][3] = Y coord    [n][5] = Height

; Array to hold other settings for each frame set
Global $aGF_SettingsIndex[1][3]
; [n][0] = Separator orientation (vert/horz = 0/1)
; [n][1] = Resizable frame flag (0/1)
; [n][2] = Separator size (default = 5)

; Array to hold WinProc handles for each separator
Global $aGF_SepProcIndex[1][2] = [[0, 0]]

; Store registered Callback handle
Global $hGF_RegCallBack = DllCallbackRegister("_GUIFrame_SepWndProc", "lresult", "hwnd;uint;wparam;lparam")
$aGF_SepProcIndex[0][1] = DllCallbackGetPtr($hGF_RegCallBack)

; #ONAUTOITEXIT FUNCTIONS# ===========================================================================================
OnAutoItExitRegister("_GUIFrame_Exit")

; #CURRENT# ==========================================================================================================
; _GUIFrame_Create:       Splits a GUI into 2 frames
; _GUIFrame_SetMin:       Sets minimum sizes for each frame
; _GUIFrame_ResizeSet:    Sets resizing flag for all or specified frame sets
; _GUIFrame_GetHandle:    Returns the handle of a frame element (required for further splitting)
; _GUIFrame_Switch:       Sets a frame element as current GUI
; _GUIFrame_GetSepPos:    Returns the current position of the separator
; _GUIFrame_SetSepPos:    Moves the separator bar to adjust frame sizes
; _GUIFrame_ResizeReg:    Registers WM_SIZE message for resizing
; _GUIFrame_SIZE_Handler: Called from a WM_SIZE message handler to resize frames using _GUIFrame_Move
; ====================================================================================================================

; #INTERNAL_USE_ONLY#=================================================================================================
; _GUIFrame_SepSubClass:   Sets new WndProc for frame separator bar
; _GUIFrame_SepWndProc:    New WndProc for frame separator bar
; _GUIFrame_SepPassMsg:    Passes Msg to original frame WndProc for action
; _GUIFrame_Move:          Moves and resizes frame elements and separator bars
; _GUIFrame_Exit:          Deletes all subclassed separator bars to free UDF WndProc and frees registered callback handle
; ====================================================================================================================

; #FUNCTION# =========================================================================================================
; Name...........: _GUIFrame_Create
; Description ...: Splits a GUI into 2 frames
; Syntax.........: _GUIFrame_Create($hWnd, $iSepOrient = 0, $iSepPos = 0, $iSepSize = 5, $iX = 0, $iY = 0, $iWidth = 0, $iHeight = 0, $iStyle = 0, $iExStyle = 0)
; Parameters ....: $hWnd - Handle of GUI to split
;                  $iSepOrient - Orientation of separator bar: 0 = Vertical (default), 1 = Horizontal
;                  $iSepPos - Required initial position of separator (default = centre of frame GUI)
;                  $iSepSize - Size of separator bar (default = 5, min = 3, max = 9)
;                  $iX - Left of frame area (default = 0)
;                  $iY - Top of frame area (default = 0)
;                  $iWidth - Width of frame area (default = full width)
;                  $iHeight - Height of frame area (default = full height)
;                  SiStyle - Required style value for frame elements
;                  SiExStyle - Required extended style value for frame elements
; Requirement(s).: v3.3 +
; Return values .: Success:  Returns index number of frame/separator set
;                  Failure:  Returns 0 and sets @error as follows:
;                  1 = Child limit exceeded
;                  2 = GUI creation failed
;                  2 = Separator subclassing failed
; Author ........: Kip
; Modified ......: Melba23
; Remarks .......:
; Example........: Yes
;=====================================================================================================================
Func _GUIFrame_Create($hWnd, $iSepOrient = 0, $iSepPos = 0, $iSepSize = 5, $iX = 0, $iY = 0, $iOrg_Width = 0, $iOrg_Height = 0, $iStyle = 0, $iExStyle = 0)

    Local $iSeperator_Pos, $hSeparator, $hFirstFrame, $hSecondFrame

    ; Set separator size
    Local $iSeparatorSize = 5
    Switch $iSepSize
        Case 3 To 9
            $iSeparatorSize = $iSepSize
    EndSwitch

    ; Set default sizing if no parameters set
    Local $iWidth = $iOrg_Width
    Local $iHeight = $iOrg_Height
    Local $aFullSize = WinGetClientSize($hWnd)
    If Not $iOrg_Width Then $iWidth = $aFullSize[0]
    If Not $iOrg_Height Then $iHeight = $aFullSize[1]

    ; Create parent GUI within client area
    Local $hParent = GUICreate("FrameParent", $iWidth, $iHeight, $iX, $iY, BitOR(0x40000000, $iStyle), $iExStyle, $hWnd) ; $WS_CHILD
    GUISetState(@SW_SHOW, $hParent)

    ; Confirm size of frame parent client area
    Local $aSize = WinGetClientSize($hParent)
    $iWidth = $aSize[0]
    $iHeight = $aSize[1]

    If $iSepOrient = 0 Then

        ; Set initial separator position
        $iSeperator_Pos = $iSepPos
        ; Adjust position if not within GUI or default set (=0)
        If $iSepPos > $iWidth Or $iSepPos < 1 Then
            $iSeperator_Pos = Round(($iWidth / 2) - ($iSeparatorSize / 2))
        EndIf
        ; Create separator bar and force cursor change over separator
        $hSeparator = GUICreate("", $iSeparatorSize, $iHeight, $iSeperator_Pos, 0, 0x40000000, -1, $hParent) ;$WS_CHILD
        GUICtrlCreateLabel("", 0, 0, $iSeparatorSize, $iHeight, -1, 0x00000001) ; $WS_EX_DLGMODALFRAME
        GUICtrlSetCursor(-1, 13)
        GUISetState(@SW_SHOW, $hSeparator)
        ; Create the sizable frames
        $hFirstFrame = GUICreate("", $iSeperator_Pos, $iHeight, 0, 0, 0x40000000, -1, $hParent) ;$WS_CHILD
        GUISetState(@SW_SHOW, $hFirstFrame)
        $hSecondFrame = GUICreate("", $iWidth - ($iSeperator_Pos + $iSeparatorSize), $iHeight, $iSeperator_Pos + $iSeparatorSize, 0, 0x40000000, -1, $hParent) ;$WS_CHILD
        GUISetState(@SW_SHOW, $hSecondFrame)

    Else

        $iSeperator_Pos = $iSepPos
        If $iSepPos > $iHeight Or $iSepPos < 1 Then
            $iSeperator_Pos = Round(($iHeight / 2) - ($iSeparatorSize / 2))
        EndIf
        $hSeparator = GUICreate("", $iWidth, $iSeparatorSize, 0, $iSeperator_Pos, 0x40000000, -1, $hParent) ;$WS_CHILD
        GUICtrlCreateLabel("", 0, 0, $iWidth, $iSeparatorSize, -1, 0x01) ; $WS_EX_DLGMODALFRAME
        GUICtrlSetCursor(-1, 11)
        GUISetState(@SW_SHOW, $hSeparator)
        $hFirstFrame = GUICreate("", $iWidth, $iSeperator_Pos, 0, 0, 0x40000000, -1, $hParent) ;$WS_CHILD
        GUISetState(@SW_SHOW, $hFirstFrame)
        $hSecondFrame = GUICreate("", $iWidth, $iHeight - ($iSeperator_Pos + $iSeparatorSize), 0, $iSeperator_Pos + $iSeparatorSize, 0x40000000, -1, $hParent) ;$WS_CHILD
        GUISetState(@SW_SHOW, $hSecondFrame)

    EndIf

    ; Check for error creating GUIs
    If $hParent = 0 Or $hSeparator = 0 Or $hFirstFrame = 0 Or $hSecondFrame = 0 Then
        ; Delete all GUIs and return error
        GUICreate($hParent)
        GUIDelete($hSeparator)
        GUIDelete($hFirstFrame)
        GUICreate($hSecondFrame)
        Return SetError(2, 0, 0)
    EndIf

    ; Subclass the separator
    If _GUIFrame_SepSubClass($hSeparator) = 0 Then
        ; If Subclassing failed then delete all GUIs and return error
        GUICreate($hParent)
        GUIDelete($hSeparator)
        GUIDelete($hFirstFrame)
        GUICreate($hSecondFrame)
        Return SetError(3, 0, 0)
    EndIf

    ; Create new lines in the storage arrays for this frame set
    Local $iIndex = $aGF_HandleIndex[0][0] + 1
    ReDim $aGF_HandleIndex[$iIndex + 1][7]
    ReDim $aGF_SizingIndex[$iIndex + 1][6]
    ReDim $aGF_SettingsIndex[$iIndex + 1][3]

    ; Store this frame set handles/variables/defaults in the new lines
    $aGF_HandleIndex[0][0] = $iIndex
    $aGF_HandleIndex[$iIndex][0] = $hParent
    $aGF_HandleIndex[$iIndex][1] = $hFirstFrame
    $aGF_HandleIndex[$iIndex][2] = $hSecondFrame
    $aGF_HandleIndex[$iIndex][3] = $hSeparator
    $aGF_HandleIndex[$iIndex][4] = $hWnd
    $aGF_HandleIndex[$iIndex][5] = 0
    $aGF_HandleIndex[$iIndex][6] = 0
    $aGF_SizingIndex[$iIndex][0] = 0
    $aGF_SizingIndex[$iIndex][1] = 0
    $aGF_SettingsIndex[$iIndex][0] = $iSepOrient
    $aGF_SettingsIndex[$iIndex][1] = 0
    $aGF_SettingsIndex[$iIndex][2] = $iSeparatorSize

    ; Store this frame index in parent line if parent is an existing frame
    For $i = 1 To $aGF_HandleIndex[0][0] - 1
        If $aGF_HandleIndex[$i][1] = $hWnd Then
            If $aGF_HandleIndex[$i][5] = 0 Then
                $aGF_HandleIndex[$i][5] = $iIndex
            Else
                $aGF_HandleIndex[$i][5] &= "|" & $iIndex
            EndIf
            ExitLoop
        EndIf
        If $aGF_HandleIndex[$i][2] = $hWnd Then
            If $aGF_HandleIndex[$i][6] = 0 Then
                $aGF_HandleIndex[$i][6] = $iIndex
            Else
                $aGF_HandleIndex[$i][6] &= "|" & $iIndex
            EndIf
            ExitLoop
        EndIf
    Next

    ; Store coordinate and size fractions
    If $iX Then
        $aGF_SizingIndex[$iIndex][2] = $iX / $aFullSize[0]
    Else
        $aGF_SizingIndex[$iIndex][2] = 0
    EndIf
    If $iY Then
        $aGF_SizingIndex[$iIndex][3] = $iY / $aFullSize[1]
    Else
        $aGF_SizingIndex[$iIndex][3] = 0
    EndIf
    If $iOrg_Width Then
        $aGF_SizingIndex[$iIndex][4] = $iOrg_Width / $aFullSize[0]
    Else
        $aGF_SizingIndex[$iIndex][4] = 1
    EndIf
    If $iOrg_Height Then
        $aGF_SizingIndex[$iIndex][5] = $iOrg_Height / $aFullSize[1]
    Else
        $aGF_SizingIndex[$iIndex][5] = 1
    EndIf

    ; Switch back to main GUI
    GUISwitch($hWnd)

    ; Return the index for this frame
    Return $iIndex

EndFunc   ;==>_GUIFrame_Create

; #FUNCTION# =========================================================================================================
; Name...........: _GUIFrame_SetMin
; Description ...: Sets minimum sizes for frames
; Syntax.........: _GUIFrame_SetMin($iFrame, $iFirstMin = 0, $iSecondMin = 0)
; Parameters ....: $iFrame - Index of frame set as returned by _GUIFrame_Create
;                  $iFirstMin - Min size of first (left/top) frame - max half size
;                  $iSecondMin - Min Size of second (right/bottom) frame - max half size
; Requirement(s).: v3.3 +
; Return values .: None
; Author ........: Melba23 based on some original code by Kip
; Modified ......:
; Remarks .......: If the frame is resized, these minima are adjusted accordingly
; Example........: Yes
;=====================================================================================================================
Func _GUIFrame_SetMin($iFrame, $iFirstMin = 0, $iSecondMin = 0)

    ; Check for valid frame index
    If $iFrame < 1 Or $iFrame > $aGF_HandleIndex[0][0] Then Return 0
    ; Get size of parent
    Local $aSize = WinGetClientSize($aGF_HandleIndex[$iFrame][0])
    ; Now check orientation and determine
    Local $iMax, $iFullSize
    If $aGF_SettingsIndex[$iFrame][0] = 0 Then
        $iMax = Floor(($aSize[0] / 2) - $aGF_SettingsIndex[$iFrame][2])
        $iFullSize = $aSize[0]
    Else
        $iMax = Floor(($aSize[1] / 2) - $aGF_SettingsIndex[$iFrame][2])
        $iFullSize = $aSize[1]
    EndIf
    ; Set minimums
    If $iFirstMin > $iMax Then
        $aGF_SizingIndex[$iFrame][0] = $iMax / $iFullSize
    Else
        $aGF_SizingIndex[$iFrame][0] = $iFirstMin / $iFullSize
    EndIf
    If $iSecondMin > $iMax Then
        $aGF_SizingIndex[$iFrame][1] = $iMax / $iFullSize
    Else
        $aGF_SizingIndex[$iFrame][1] = $iSecondMin / $iFullSize
    EndIf

EndFunc   ;==>_GUIFrame_SetMin

; #FUNCTION# =========================================================================================================
; Name...........: _GUIFrame_ResizeSet
; Description ...: Sets resizing flag for frames
; Syntax.........: _GUIFrame_ResizeSet($iFrame = 0)
; Parameters ....: $iFrame - Index of frame set as returned by _GUIFrame_Create
;                  (Default - 0 = all existing frames)
; Requirement(s).: v3.3 +
; Return values .: Success: 2 - All existing frame flags set
;                           1 - Specified flag set
;                  Failure: 0 with @error set to 1 - Invalid frame specified
; Author ........: Melba23
; Modified ......:
; Remarks .......:
; Example........: Yes
;=====================================================================================================================
Func _GUIFrame_ResizeSet($iFrame = 0)

    Switch $iFrame
        Case 0 ; Set all frames
            For $i = 1 To $aGF_HandleIndex[0][0]
                $aGF_SettingsIndex[$i][1] = 1
            Next
            Return 2
        Case 1 To $aGF_HandleIndex[0][0] ; Only valid frames accepted
            $aGF_SettingsIndex[$iFrame][1] = 1
            Return 1
        Case Else ; Error
            Return SetError(1, 0, 0)
    EndSwitch

EndFunc   ;==>_GUIFrame_ResizeSet

; #FUNCTION# =========================================================================================================
; Name...........: _GUIFrame_GetHandle
; Description ...: Returns the handle of a frame element (required for further splitting)
; Syntax.........: _GUIFrame_GetHandle($iFrame, $iElement)
; Parameters ....: $iFrame - Index of frame set as returned by _GUIFrame_Create
;                  $iElement - 1 = first (left/top) frame, 2 = second (right/bottom) frame
; Requirement(s).: v3.3 +
; Return values .: Success: Handle of frame
;                  Failure: 0 with @error set as follows
;                           1 - Invalid frame specified
;                           2 - Invalid element specified
; Author ........: Kip
; Modified ......: Melba23
; Remarks .......: _GUIFrame_Create requires a GUI handle as a parameter
; Example........: Yes
;=====================================================================================================================
Func _GUIFrame_GetHandle($iFrame, $iElement)

    ; Check valid frame index and element
    Switch $iFrame
        Case 1 To $aGF_HandleIndex[0][0]
            Switch $iElement
                Case 1, 2
                    ; Return handle
                    Return $aGF_HandleIndex[$iFrame][$iElement]
            EndSwitch
            Return SetError(2, 0, 0)
    EndSwitch
    Return SetError(1, 0, 0)

EndFunc   ;==>_GUIFrame_GetHandle

; #FUNCTION# =========================================================================================================
; Name...........: _GUIFrame_Switch
; Description ...: Sets a frame element as current GUI
; Syntax.........: _GUIFrame_Switch($iFrame, $iElement)
; Parameters ....: $iFrame - Index of frame set as returned by _GUIFrame_Create
;                  $iElement - 1 = first (left/top) frame, 2 = second (right/bottom) frame
; Requirement(s).: v3.3 +
; Return values .: None
; Author ........: Kip
; Modified ......: Melba23
; Remarks .......: Subsequent controls are created in the specified frame element
; Example........: Yes
;=====================================================================================================================
Func _GUIFrame_Switch($iFrame, $iElement)

    ; Check valid frame index and element
    Switch $iFrame
        Case 1 To $aGF_HandleIndex[0][0]
            Switch $iElement
                Case 1, 2
                    ; Switch to specified element
                    Return GUISwitch($aGF_HandleIndex[$iFrame][$iElement])
            EndSwitch
            Return SetError(2, 0, 0)
    EndSwitch
    Return SetError(1, 0, 0)

EndFunc   ;==>_GUIFrame_Switch

; #FUNCTION# =========================================================================================================
; Name...........: _GUIFrame_GetSepPos()
; Description ...: Returns the current position of the separator
; Syntax.........: _GUIFrame_GetSepPos($iFrame)
; Parameters ....: $iFrame - Index of frame set as returned by _GUIFrame_Create
; Requirement(s).: v3.3 +
; Return values .: Success: Position of separator
;                  Failure: -1 = Invalid frame specified
; Author ........: Melba23
; Remarks .......: This value can be stored and used as the initial separator position parameter in _GUIFrame_Create
;                  to restore exit position on restart
; Example........: Yes
;=====================================================================================================================
Func _GUIFrame_GetSepPos($iFrame)

    Local $iSepPos

    ; Check for valid frame index
    If $iFrame < 1 Or $iFrame > $aGF_HandleIndex[0][0] Then Return -1

    ; Get position of first frame
    Local $aFrame_Pos = WinGetPos($aGF_HandleIndex[$iFrame][1])
    ; Get position of separator
    Local $aSep_Pos = WinGetPos($aGF_HandleIndex[$iFrame][3])
    ; Check on separator orientation
    If $aGF_SettingsIndex[$iFrame][0] Then
        $iSepPos = $aSep_Pos[1] - $aFrame_Pos[1]
    Else
        $iSepPos = $aSep_Pos[0] - $aFrame_Pos[0]
    EndIf
    Return $iSepPos

EndFunc

; #FUNCTION# =========================================================================================================
; Name...........: _GUIFrame_SetSepPos()
; Description ...: Moves the separator bar to adjust frame sizes
; Syntax.........: _GUIFrame_SetSepPos($iFrame, $iSepPos)
; Parameters ....: $iFrame - Index of frame set as returned by _GUIFrame_Create
;                  $iSepos - Position of separator bar within frame
; Requirement(s).: v3.3 +
; Return values .: Success: 1
;                  Failure: 0 with @error set as follows
;                           1 - Invalid frame specified
;                           2 - Invalid separator position (outside frame)
;                           3 - Invalid separator position (below frame minimum size)
; Author ........: Melba23
; Remarks .......: This value can be stored and used as the initial separator position parameter in _GUIFrame_Create
;                  to restore exit position on restart
; Example........: Yes
;=====================================================================================================================
Func _GUIFrame_SetSepPos($iFrame, $iSepPos)

    Local $iFirstMin, $iSecondMin

    ; Check for valid frame index
    If $iFrame < 1 Or $iFrame > $aGF_HandleIndex[0][0] Then Return SetError(1, 0, 0)

    ; Check separator actually needs to move
    If $iSepPos = _GUIFrame_GetSepPos($iFrame) Then Return 1

    ; Get frame GUI size
    Local $aWinPos = WinGetPos($aGF_HandleIndex[$iFrame][0])
    ; Depending on separator orientation
    If $aGF_SettingsIndex[$iFrame][0] Then
        ; Check sep position is valid
        If $iSepPos < 0 Or $iSepPos > $aWinPos[3] Then Return SetError(2, 0, 0)
        ; Determine minima for frames
        $iFirstMin = $aWinPos[3] * $aGF_SizingIndex[$iFrame][0]
        $iSecondMin = ($aWinPos[3] * (1 - $aGF_SizingIndex[$iFrame][1])) - $aGF_SettingsIndex[$iFrame][2]
        ; Check required value is valid
        If $iSepPos < $iFirstMin Or $iSepPos > $iSecondMin Then Return SetError(3, 0, 0)
        ; Move frames and seperator
        WinMove($aGF_HandleIndex[$iFrame][1], "", 0, 0, $aWinPos[2], $iSepPos)
        WinMove($aGF_HandleIndex[$iFrame][2], "", 0, $iSepPos + $aGF_SettingsIndex[$iFrame][2], $aWinPos[2], $aWinPos[3] - ($iSepPos + $aGF_SettingsIndex[$iFrame][2]))
        WinMove($aGF_HandleIndex[$iFrame][3], "", 0, $iSepPos, $aWinPos[2], $aGF_SettingsIndex[$iFrame][2])
    Else
        If $iSepPos < 0 Or $iSepPos > $aWinPos[2] Then Return SetError(2, 0, 0)
        $iFirstMin = $aWinPos[2] * $aGF_SizingIndex[$iFrame][0]
        $iSecondMin = ($aWinPos[2] * (1 - $aGF_SizingIndex[$iFrame][1])) - $aGF_SettingsIndex[$iFrame][2]
        If $iSepPos < $iFirstMin Or $iSepPos > $iSecondMin Then Return SetError(3, 0, 0)
        WinMove($aGF_HandleIndex[$iFrame][1], "", 0, 0, $iSepPos, $aWinPos[3])
        WinMove($aGF_HandleIndex[$iFrame][2], "", $iSepPos + $aGF_SettingsIndex[$iFrame][2], 0, $aWinPos[2] - ($iSepPos + $aGF_SettingsIndex[$iFrame][2]), $aWinPos[3])
        WinMove($aGF_HandleIndex[$iFrame][3], "", $iSepPos, 0, $aGF_SettingsIndex[$iFrame][2], $aWinPos[3])
    EndIf
    Return 1

EndFunc

; #FUNCTION# =========================================================================================================
; Name...........: _GUIFrame_ResizeReg
; Description ...: Registers WM_SIZE message for resizing
; Syntax.........: _GUIFrame_ResizeReg()
; Parameters ....: None
; Requirement(s).: v3.3 +
; Return values .: Success: 1 - Message handler registered
;                  Failure: 0 with @error set to 1 - Message handler already registered
; Author ........: Melba23
; Modified ......:
; Remarks .......:
; Example........: Yes
;=====================================================================================================================
Func _GUIFrame_ResizeReg()

    ; Register the WM_SIZE message
    If $aGF_HandleIndex[0][1] = 0 Then
        Local $iRet = GUIRegisterMsg(0x05, "_GUIFrame_SIZE_Handler") ; $WM_SIZE
        If $iRet Then
            $aGF_HandleIndex[0][1] = 1
            Return 1
        EndIf
    EndIf
    Return SetError(1, 0, 0)

EndFunc   ;==>_GUIFrame_ResizeReg

; #FUNCTION# =========================================================================================================
; Name...........: _GUIFrame_SIZE_Handler
; Description ...: Used to resize frames when resizing of holding GUI occurs
; Syntax.........: _GUIFrame_SIZE_Handler($hWnd, $iMsg, $wParam, $lParam)
; Parameters ....: None
; Requirement(s).: v3.3 +
; Return values .: None
; Author ........: Melba23
; Modified ......:
; Remarks .......: If the script already has a WM_SIZE handler, then just call this function from within it
;                  and do NOT use the _GUIFrame_ResizeReg function
; Example........: Yes
;=====================================================================================================================
Func _GUIFrame_SIZE_Handler($hWnd, $iMsg, $wParam, $lParam)

    #forceref $iMsg, $wParam, $lParam
    Local $iIndex

    ; Get index of base frame GUI
    For $iIndex = 1 To $aGF_HandleIndex[0][0]
        If $aGF_HandleIndex[$iIndex][4] = $hWnd Then ExitLoop
    Next

    ; If handle not found
    If $iIndex > $aGF_HandleIndex[0][0] Then Return "GUI_RUNDEFMSG"

    ; Check if we should resize this set
    If $aGF_SettingsIndex[$iIndex][1] = 1 Then

        ; Get new base GUI size
        Local $aSize = WinGetClientSize($hWnd)
        ; Resize frames
        _GUIFrame_Move($iIndex, $aSize[0] * $aGF_SizingIndex[$iIndex][2], $aSize[1] * $aGF_SizingIndex[$iIndex][3], $aSize[0] * $aGF_SizingIndex[$iIndex][4], $aSize[1] * $aGF_SizingIndex[$iIndex][5])

        ; Adjust any resizeable internal frames - array elements are adjacent for ease of coding
        For $i = 0 To 1
            ; Adjust internal frames of first/second frame if any exist
            If $aGF_HandleIndex[$iIndex][5 + $i] <> 0 Then
                ; StringSplit the element content on "|"
                Local $aInternal = StringSplit($aGF_HandleIndex[$iIndex][5 + $i], "|")
                ; Then loop though the Number(values) found
                For $j = 1 To $aInternal[0]
                    Local $iIntIndex = Number($aInternal[$j])
                    ; Check if internal frame is resizable
                    If $aGF_SettingsIndex[$iIntIndex][1] = 1 Then
                        ; And change if so
                        _GUIFrame_SIZE_Handler($aGF_HandleIndex[$iIntIndex][4], $iMsg, $wParam, $lParam)
                    EndIf
                Next
            EndIf
        Next

    EndIf

    Return "GUI_RUNDEFMSG"

EndFunc   ;==>_GUIFrame_SIZE_Handler

; #INTERNAL_USE_ONLY#============================================================================================================
; Name...........: _GUIFrame_SepSubClass
; Description ...: Sets new WndProc for frame separator bar
; Author ........: Kip
; Modified.......: Melba23, using SetWindowLongPtr x64 compatible code drawn from Yashied's WinAPIEx library
; Remarks .......: This function is used internally by _GUIFrame_Create
; ===============================================================================================================================
Func _GUIFrame_SepSubClass($hWnd)

    Local $aRet

    ; Check separator has not already been used
    For $i = 1 To $aGF_SepProcIndex[0][0]
        If $aGF_SepProcIndex[$i][0] = $hWnd Then Return 0
    Next

    ; Store current WinProc handle in new array line
    Local $iIndex = $aGF_SepProcIndex[0][0] + 1
    ReDim $aGF_SepProcIndex[$iIndex + 1][2]
    $aGF_SepProcIndex[0][0] = $iIndex
    $aGF_SepProcIndex[$iIndex][0] = $hWnd
    ; Subclass separator bar
    If @AutoItX64 Then
        $aRet = DllCall('user32.dll', 'long_ptr', 'SetWindowLongPtrW', 'hwnd', $hWnd, 'int', -4, 'long_ptr', $aGF_SepProcIndex[0][1]) ; $GWL_WNDPROC
    Else
        $aRet = DllCall('user32.dll', 'long', 'SetWindowLongW', 'hwnd', $hWnd, 'int', -4, 'long', $aGF_SepProcIndex[0][1]) ; $GWL_WNDPROC
    EndIf
    ; Check for subclassing error
    If @error Or $aRet[0] = 0 Then Return 0
    ; Return success
    $aGF_SepProcIndex[$iIndex][1] = $aRet[0]
    Return 1

EndFunc   ;==>_GUIFrame_SepSubClass

; #INTERNAL_USE_ONLY#============================================================================================================
; Name...........: _GUIFrame_SepWndProc
; Description ...: New WndProc for frame separator bar
; Author ........: Kip
; Modified.......: Melba23
; Remarks .......: This function is used internally by _GUIFrame_SepSubClass
; ===============================================================================================================================
Func _GUIFrame_SepWndProc($hWnd, $iMsg, $wParam, $lParam)

    Local $iSubtract

    If $iMsg = 0x0111 Then ; WM_COMMAND

        ; Check if hWnd is a Separator bar
        For $iIndex = 1 To $aGF_HandleIndex[0][0]
            If $aGF_HandleIndex[$iIndex][3] = $hWnd Then ExitLoop
        Next
        ; If not then pass message on to org WndProc
        If $iIndex > $aGF_HandleIndex[0][0] Then Return _GUIFrame_SepPassMsg($hWnd, $iMsg, $wParam, $lParam)

        ; Extract values from array
        Local $hParent = $aGF_HandleIndex[$iIndex][0]
        Local $hFirstFrame = $aGF_HandleIndex[$iIndex][1]
        Local $hSecondFrame = $aGF_HandleIndex[$iIndex][2]
        Local $hSeparator = $aGF_HandleIndex[$iIndex][3]
        Local $iFirstMin = $aGF_SizingIndex[$iIndex][0]
        Local $iSecondMin = $aGF_SizingIndex[$iIndex][1]
        Local $iSeparatorSize = $aGF_SettingsIndex[$iIndex][2]

        ; Get client size of the parent
        Local $aClientSize = WinGetClientSize($hParent)
        Local $iWidth = $aClientSize[0]
        Local $iHeight = $aClientSize[1]

        ; Get cursor info for the Separator
        Local $aCInfo = GUIGetCursorInfo($hSeparator)

        ; Depending on separator orientation
        If $aGF_SettingsIndex[$iIndex][0] = 0 Then

            ; Get Separator X-coord
            $iSubtract = $aCInfo[0]

            Do
                ; Get parent X-coord
                $aCInfo = GUIGetCursorInfo($hParent)
                Local $iCursorX = $aCInfo[0]

                ; Determine width of first frame
                Local $iFirstWidth = $iCursorX - $iSubtract
                ; And ensure it is at least minimum
                If $iFirstWidth < $iWidth * $iFirstMin Then $iFirstWidth = $iWidth * $iFirstMin
                If $iWidth - ($iFirstWidth + $iSeparatorSize) < $iWidth * $iSecondMin Then $iFirstWidth = $iWidth - ($iWidth * $iSecondMin) - $iSeparatorSize

                ; Move the GUIs to the correct places
                WinMove($hFirstFrame, "", 0, 0, $iFirstWidth, $iHeight)
                WinMove($hSecondFrame, "", $iFirstWidth + $iSeparatorSize, 0, $iWidth - ($iFirstWidth + $iSeparatorSize), $iHeight)
                WinMove($hSeparator, "", $iFirstWidth, 0, $iSeparatorSize, $iHeight)

                ; Do until the mouse button is released
            Until Not _WinAPI_GetAsyncKeyState(0x01)

        ElseIf $aGF_SettingsIndex[$iIndex][0] = 1 Then

            $iSubtract = $aCInfo[1]
            Do
                $aCInfo = GUIGetCursorInfo($hParent)
                Local $iCursorY = $aCInfo[1]
                Local $iFirstHeight = $iCursorY - $iSubtract
                If $iFirstHeight < $iHeight * $iFirstMin Then $iFirstHeight = $iHeight * $iFirstMin
                If $iHeight - ($iFirstHeight + $iSeparatorSize) < $iHeight * $iSecondMin Then $iFirstHeight = $iHeight - ($iHeight * $iSecondMin) - $iSeparatorSize
                WinMove($hFirstFrame, "", 0, 0, $iWidth, $iFirstHeight)
                WinMove($hSecondFrame, "", 0, $iFirstHeight + $iSeparatorSize, $iWidth, $iHeight - ($iFirstHeight + $iSeparatorSize))
                WinMove($hSeparator, "", 0, $iFirstHeight, $iWidth, $iSeparatorSize)
            Until Not _WinAPI_GetAsyncKeyState(0x01)

        EndIf

    EndIf

    ; Pass the message on to org WndProc
    Return _GUIFrame_SepPassMsg($hWnd, $iMsg, $wParam, $lParam)

EndFunc   ;==>_GUIFrame_SepWndProc

; #INTERNAL_USE_ONLY#============================================================================================================
; Name...........: _GUIFrame_SepPassMsg
; Description ...: Passes Msg to frame parent WndProc for action
; Author ........: Kip
; Modified.......: Melba23
; Remarks .......: This function is used internally by _GUIFrame_SepWndProc
; ===============================================================================================================================
Func _GUIFrame_SepPassMsg($hWnd, $iMsg, $wParam, $lParam)

    For $i = 1 To $aGF_SepProcIndex[0][0]
        If $aGF_SepProcIndex[$i][0] = $hWnd Then Return _WinAPI_CallWindowProc($aGF_SepProcIndex[$i][1], $hWnd, $iMsg, $wParam, $lParam)
    Next

EndFunc   ;==>_GUIFrame_SepPassMsg

; #INTERNAL_USE_ONLY#============================================================================================================
; Name...........: _GUIFrame_Move
; Description ...: Moves and resizes frame elements and separator bars
; Author ........: Kip
; Modified.......: Melba23
; Remarks .......: This function is used internally by _GUIFrame_SIZE_Handler
; ===============================================================================================================================
Func _GUIFrame_Move($iFrame, $iX, $iY, $iWidth = 0, $iHeight = 0)

    ; Check valid frame index
    If $iFrame < 1 Or $iFrame > $aGF_HandleIndex[0][0] Then Return 0

    Local $iSeparatorSize = $aGF_SettingsIndex[$iFrame][2]
    Local $iTotal

    ; Set size if not specified
    If Not $iWidth Then $iWidth = _WinAPI_GetWindowWidth($aGF_HandleIndex[$iFrame][0])
    If Not $iHeight Then $iHeight = _WinAPI_GetWindowHeight($aGF_HandleIndex[$iFrame][0])

    ; Move parent
    WinMove($aGF_HandleIndex[$iFrame][0], "", $iX, $iY, $iWidth, $iHeight)

    ; Get size of first frame depending on orientation
    Local $aWinPos = WinGetClientSize($aGF_HandleIndex[$iFrame][1])
    Local $iSize = $aWinPos[0]
    If $aGF_SettingsIndex[$iFrame][0] = 1 Then $iSize = $aWinPos[1]

    ; Set frame min percentages
    Local $iFirstMin = $aGF_SizingIndex[$iFrame][0]
    Local $iSecondMin = $aGF_SizingIndex[$iFrame][1]

    ; Depending on separator orientation
    If $aGF_SettingsIndex[$iFrame][0] = 0 Then

        ; Move frames and separator as required
        $iTotal = $iWidth
        If $iSize < $iWidth * $iFirstMin Then $iSize = $iWidth * $iFirstMin
        If $iTotal - $iSize - $iSeparatorSize < $iWidth * $iSecondMin Then $iSize = $iTotal - ($iWidth * $iSecondMin) - $iSeparatorSize
        WinMove($aGF_HandleIndex[$iFrame][1], "", 0, 0, $iSize, $iHeight)
        WinMove($aGF_HandleIndex[$iFrame][2], "", $iSize + $iSeparatorSize, 0, $iTotal - $iSize - $iSeparatorSize, $iHeight)
        WinMove($aGF_HandleIndex[$iFrame][3], "", $iSize, 0, $iSeparatorSize, $iHeight)

    ElseIf $aGF_SettingsIndex[$iFrame][0] = 1 Then

        $iTotal = $iHeight
        If $iSize < $iHeight * $iFirstMin Then $iSize = $iHeight * $iFirstMin
        If $iTotal - $iSize - $iSeparatorSize < $iHeight * $iSecondMin Then $iSize = $iTotal - ($iHeight * $iSecondMin) - $iSeparatorSize
        WinMove($aGF_HandleIndex[$iFrame][1], "", 0, 0, $iWidth, $iSize)
        WinMove($aGF_HandleIndex[$iFrame][2], "", 0, $iSize + $iSeparatorSize, $iWidth, $iTotal - $iSize - $iSeparatorSize)
        WinMove($aGF_HandleIndex[$iFrame][3], "", 0, $iSize, $iWidth, $iSeparatorSize)

    EndIf

EndFunc   ;==>_GUIFrame_Move

; #INTERNAL_USE_ONLY#============================================================================================================
; Name...........: _GUIFrame_Exit()
; Description ...: Deletes all subclassed separator bars to free UDF WndProc and frees registered callback handle
; Author ........: Melba23
; Remarks .......: Called by OnAutoItExitRegister to delete all subclassed separator bars and to free the UDF created WndProc.
; Example........: Yes
;================================================================================================================================
Func _GUIFrame_Exit()

    ; Delete all subclassed separator bars
    For $i = $aGF_HandleIndex[0][0] To 1 Step -1
        GUIDelete($aGF_HandleIndex[$i][3])
    Next
    ; Free registered Callback handle
    DllCallbackFree($hGF_RegCallBack)

EndFunc   ;==>_GUIFrame_Exit

And if anyone else wants to test as well, please do so.

M23

[Melba23]

I knew something was tickling the back of my mind - this problem (and the solution) was already reported here. I will get a new version of the UDF out this weekend - unless anyone comes up with a new problem before then.

M23

[ptrex]

@Melba

So far so good !

Ran several tests on x64.

Thanks

Rgds

ptrex

[Mikeman27294]

Yep. I made the replacement or @OS_ARCH and it works perfectly on the 32 bit interpretor.

[Melba23]

[NEW VERSION] - 20 Jan 12

Changed: Code amended to allow UDF to work on x64 systems with the 32bit AutoIt executable.

New UDF and zip in first post.

M23

[Melba23]

[NEW VERSION] - 4 Feb 12

Changed: Controls with accelerator letters in the titles (set by &) now work. Thanks to DicatoroftheUSA for reporting the problem and ProgAndy for coming up with the solution (and also pointing out a couple of typos).

New UDF in the post and zip file in first post.

M23

[DicatoroftheUSA]

Thanks for the update M23, you are an inspiriation.

Edited February 4, 2012 by DicatoroftheUSA

[KaFu]

Hi m8,

running this on a Win7 64bit OS as a 32bit process, it hangs from time to time while rendering the initial GUI. Restart the example multiple times to see the effect. Clicking the GUI or drawing the borders will make the script continue to render the frames. I've already taken deeper look but couldn't identify the issue. First thought it was this

If you have changed certain window data using SetWindowLong, you must call SetWindowPos for the changes to take effect. Use the following combination for uFlags: SWP_NOMOVE | SWP_NOSIZE | SWP_NOZORDER | SWP_FRAMECHANGED.

but adding a call after the SetWindowLong did not help.

Regards

[Melba23]

Kafu,

It hangs for me on Vista x32 from time to time as well, so I do not believe it is an x32/x64 problem.

I have tried several possible solutions with no effect. If you do find one, please let me know.

M23

[KaFu]

Just an idea, is it possible that this passage from the help-file for GUIRegisterMsg() applies to this situation:

"Warning: blocking of running user functions which executes window messages with commands such as "Msgbox()" can lead to unexpected behavior, the return to the system should be as fast as possible !!!"

, that your custom winproc is to complex and chokes the message queue somehow randomly.

Edit: No truly randomly but e.g. during processor usage peaks? Would a custom buffer solve this?

Edited March 13, 2012 by KaFu

[ResNullius]

@Melba23,

Maybe I'm just daft, but there seems to be a problem with the individual GUI frames created in terms of, shall I say, their "stickiness".

If I fire up your "GUIFrame_Example_1.au3" as included in the current download and click and drag say the green background in the upper left frame, the whole thing moves.

If I now click and drag on some of the exposed "white" space where the green used to be, I can clcik and drag the whole left half of the GUI, top, bottom, and horizontal split.

If I click and drag the red right half of the GUI and then click and drag on the exposed white space there, the Entire inside of the GUI with all dividers and child objects can be dragged around.

I have reproduced this problem on two different computers, both running the latest stable build of AutoIt 3.3.8.1.

Can you reproduce? If so, is that behaviour by design or is there a bit that hasn't been flipped somewhere.

I was looking forward to using this in a new project, but I can't trust my users not to idly click and drag things around

Thanks

[Melba23]

ResNullius,

but I can't trust my users not to idly click and drag things around

I now feel the same way - why do people have to fiddle!

I can reproduce the behaviour - thanks for pointing it out. It is certainly not by design and I will look into it.

M23

[Melba23]

ResNullius,

That did not take long - I wondered why no-one had reported it before as it seems such an obvious bug so I looked at recent changes to the UDF. I had added the $WS_EX_CONTROLPARENT style to the frames as a result of this thread.

But I knew in the back of my mind that there was a problem with that style and in fact the addition of that style is what is causing the "dragging" problem. Alas there is little I can do to prevent the problem if I retain the style - as you can see from Valik's response to the Trac report #1115.

I will have a think about how best to proceed from here - perhaps an option to use the style or not might be the solution.

Again thanks for the report.

M23
