Resources UDF

[inet]

Hi Guys,

Zedna, super UDF. It's making life a lot easier muttley

Hope you guys can help me with the following:

I am making this GUI and combined the use of the resources UDF with the tranparent GUI loader of Lod3n from this posting:

Lod3n loader

I manage to get the Main GUI on screen, bij loading it from a .png embedded in the .exe it even fades in, so that part is working, then there has to loaded a .gif with the transparancy color, that one is loaded from embeded resource too. That part seems to be working too, because the main GUI on the screen is transparent.

Then i am trying to put all the controls on the GUI, but that part seems to fail, i only see the main GUI with none of the controls on screen. I tried different approaches but i cannot seem to get it right, i hope you guys can help me out here...

First the Lod3en code for transparent GUI:

expandcollapse popup

#NoTrayIcon
#include <WindowsConstants.au3>
#include <StructureConstants.au3>
#include <GUIConstantsEx.au3>
#Include <GDIPlus.au3>; this is where the magic happens, people
;#include <GuiComboBox.au3>
#Include <File.au3>
#include <Array.au3>
#include <ButtonConstants.au3>
;Opt("MustDeclareVars", 0)

Global Const $AC_SRC_ALPHA = 1
;Global Const $ULW_ALPHA = 2
Global $old_string = "", $runthis = ""
Global $launchDir = @DesktopDir

; Load PNG file as GDI bitmap
_GDIPlus_Startup()
$pngSrc = @ScriptDir & "\test.png"
$hImage = _GDIPlus_ImageLoadFromFile($pngSrc)

; Extract image width and height from PNG
$width = _GDIPlus_ImageGetWidth($hImage)
$height = _GDIPlus_ImageGetHeight($hImage)

; Create layered window
$GUI = GUICreate("lod3n launcher", $width, $height, -1, -1, $WS_POPUP, $WS_EX_LAYERED)
SetBitmap($GUI, $hImage, 0)
; Register notification messages
GUIRegisterMsg($WM_NCHITTEST, "WM_NCHITTEST")
GUISetState()
WinSetOnTop($GUI, "", 1)
;fade in png background
For $i = 0 To 255 Step 1        ; The higher the Step the faster the fade in
    SetBitmap($GUI, $hImage, $i)
Next


; create child MDI gui window to hold controls
; this part could use some work - there is some flicker sometimes...
$controlGui = GUICreate("ControlGUI", $width, $height, 0, 0, $WS_POPUP, BitOR($WS_EX_LAYERED, $WS_EX_MDICHILD), $GUI)

; child window transparency is required to accomplish the full effect, so $WS_EX_LAYERED above, and
; I think the way this works is the transparent window color is based on the image you set here:
GUICtrlCreatePic(@ScriptDir & "\grey.gif", 0, 0, $width, $height)
GUICtrlSetState(-1, $GUI_DISABLE)

; just a text label
GUICtrlCreateLabel("Test press escape to quit...", 100, 112, 240, 150)
GUICtrlSetBkColor(-1, $GUI_BKCOLOR_TRANSPARENT)
GUICtrlSetColor(-1, 0x808080)

GUISetState()

;Loop that keeps the GUI running until pressed ESC
While 1
    $msg = GUIGetMsg()
    Select
        Case $msg = $GUI_EVENT_CLOSE
            ExitLoop

    EndSelect
WEnd
AdlibDisable()

GUIDelete($controlGui)
;fade out png background
For $i = 255 To 0 Step - 1          ; The higher the Step, the faster the fade out
    SetBitmap($GUI, $hImage, $i)
Next

; Release resources
_GDIPlus_ImageDispose($hImage)
_GDIPlus_Shutdown()

;===================================================================================================


; Handle the WM_NCHITTEST for the layered window so it can be dragged by clicking anywhere on the image.
;===================================================================================================



Func WM_NCHITTEST($hWnd, $iMsg, $iwParam, $ilParam)
    If ($hWnd = $GUI) And ($iMsg = $WM_NCHITTEST) Then Return $HTCAPTION
EndFunc  ;==>WM_NCHITTEST

;===================================================================================================


; SetBitMap
;===================================================================================================



Func SetBitmap($hGUI, $hImage, $iOpacity)
    Local $hScrDC, $hMemDC, $hBitmap, $hOld, $pSize, $tSize, $pSource, $tSource, $pBlend, $tBlend

    $hScrDC = _WinAPI_GetDC(0)
    $hMemDC = _WinAPI_CreateCompatibleDC($hScrDC)
    $hBitmap = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hImage)
    $hOld = _WinAPI_SelectObject($hMemDC, $hBitmap)
    $tSize = DllStructCreate($tagSIZE)
    $pSize = DllStructGetPtr($tSize)
    DllStructSetData($tSize, "X", _GDIPlus_ImageGetWidth($hImage))
    DllStructSetData($tSize, "Y", _GDIPlus_ImageGetHeight($hImage))
    $tSource = DllStructCreate($tagPOINT)
    $pSource = DllStructGetPtr($tSource)
    $tBlend = DllStructCreate($tagBLENDFUNCTION)
    $pBlend = DllStructGetPtr($tBlend)
    DllStructSetData($tBlend, "Alpha", $iOpacity)
    DllStructSetData($tBlend, "Format", $AC_SRC_ALPHA)
    _WinAPI_UpdateLayeredWindow($hGUI, $hScrDC, 0, $pSize, $hMemDC, $pSource, 0, $pBlend, $ULW_ALPHA)
    _WinAPI_ReleaseDC(0, $hScrDC)
    _WinAPI_SelectObject($hMemDC, $hOld)
    _WinAPI_DeleteObject($hBitmap)
    _WinAPI_DeleteDC($hMemDC)
EndFunc  ;==>SetBitmap

; I don't like AutoIt's built in ShellExec. I'd rather do the DLL call myself.
Func _ShellExecute($sCmd, $sArg = "", $sFolder = "", $rState = @SW_SHOWNORMAL)
    $aRet = DllCall("shell32.dll", "long", "ShellExecute", _
            "hwnd", 0, _
            "string", "", _
            "string", $sCmd, _
            "string", $sArg, _
            "string", $sFolder, _
            "int", $rState)
    If @error Then Return 0

    $RetVal = $aRet[0]
    If $RetVal > 32 Then
        Return 1
    Else
        Return 0
    EndIf
EndFunc  ;==>_ShellExecute

Now my code:

expandcollapse popup

$GUIpic1 = GUICtrlCreatePic("",0,0,900,300)
$GUIpic2 = GUICtrlCreatePic("",0,0,900,300)
_ResourceSetImageToCtrl($GUIpic1, "KABOOKIE_PIC_1")
_ResourceSetImageToCtrl($GUIpic2, "GREY_1")
;$size1 = _ResourceGetImageSize("KABOOKIE_PIC_1")
$hImage = _ResourceGetAsImage("KABOOKIE_PIC_1", 10)
$TransPic = _ResourceGetAsImage("GREY_1", 10)

;==================== Transparent GUI Loading =============
_GDIPlus_Startup()
;$pngSrc = @ScriptDir & "\Kabookie IM.png"
;$hImage = _GDIPlus_ImageLoadFromFile($pngSrc)

; Extract image width and height from PNG
$width = _GDIPlus_ImageGetWidth($hImage)
$height = _GDIPlus_ImageGetHeight($hImage)
;==================== Transparent GUI Loading End =========

;==================== Build Up GUI ========================
$MainGUI = GUICreate("Kabookie - Intra Messaging V 0.10b  -  Levix Edition", $width, $height, -1, -1, BitOr($WS_POPUP,$WS_MINIMIZEBOX), $WS_EX_LAYERED)

SetBitmap($MainGUI, $hImage, 0)

; Register notification messages
GUIRegisterMsg($WM_NCHITTEST, "WM_NCHITTEST")
GUISetState()
;WinSetOnTop($MainGUI, "", 1)
;fade in png background
For $i = 0 To 255 Step 1        ; The higher the Step the faster the fade in
    SetBitmap($MainGUI, $hImage, $i)
Next

; create child MDI gui window to hold controls
; this part could use some work - there is some flicker sometimes...
$controlGui = GUICreate("ControlGUI", $width, $height, 0, 0, $WS_POPUP, BitOR($WS_EX_LAYERED, $WS_EX_MDICHILD), $MainGUI)

; child window transparency is required to accomplish the full effect, so $WS_EX_LAYERED above, and
; I think the way this works is the transparent window color is based on the image you set here:
GUICtrlCreatePic($GUIpic2, 0, 0, $width, $height)
GUICtrlSetState(-1, $GUI_DISABLE)

$ConIPGroup = GUICtrlCreateGroup("", 650, 178, 205, 362)
GUICtrlSetFont(-1, 8.5,"Times New Roman")
GUICtrlSetBkColor(-1, $GUI_BKCOLOR_TRANSPARENT)
GUICtrlSetColor(-1, 0xFFFFFF)
$ConnectedIP = GUICtrlCreateListView("", 668, 196, 175, 292, BitOR($LVS_SORTASCENDING,$LVS_LIST,$LVS_SINGLESEL,$LVS_SHOWSELALWAYS,$WS_VSCROLL,$WS_BORDER))
_GUICtrlListView_SetColumnWidth($ConnectedIP, 0, 175)
GUICtrlSetFont(-1, 9,"Times New Roman")
GUICtrlSetColor(-1, 0x000000)
$EditIPBut = GUICtrlCreateButton("Edit", 782, 514, 61, 19)
GUICtrlSetState(-1, $GUI_DISABLE)

..........more controls added here...

GUISetState(@SW_SHOW)

Hope you guys can see why my controls are never put to screen..

[Zedna]

...

1) you can't use GUICtrlCreatePic() before GUICreate()

2)

instead of

GUICtrlCreatePic($GUIpic2, 0, 0, $width, $height)

use

$GUIpic2 = GUICtrlCreatePic("", 0, 0, $width, $height)

_ResourceSetImageToCtrl($GUIpic2, "KABOOKIE_PIC_1")

Here is code (not tested):

expandcollapse popup

;~ $GUIpic1 = GUICtrlCreatePic("",0,0,900,300)
;~ $GUIpic2 = GUICtrlCreatePic("",0,0,900,300)
;~ _ResourceSetImageToCtrl($GUIpic1, "KABOOKIE_PIC_1")
;~ _ResourceSetImageToCtrl($GUIpic2, "GREY_1")
;$size1 = _ResourceGetImageSize("KABOOKIE_PIC_1")
$hImage = _ResourceGetAsImage("KABOOKIE_PIC_1", 10)
$TransPic = _ResourceGetAsImage("GREY_1", 10)

;==================== Transparent GUI Loading =============
_GDIPlus_Startup()
;$pngSrc = @ScriptDir & "\Kabookie IM.png"
;$hImage = _GDIPlus_ImageLoadFromFile($pngSrc)

; Extract image width and height from PNG
$width = _GDIPlus_ImageGetWidth($hImage)
$height = _GDIPlus_ImageGetHeight($hImage)
;==================== Transparent GUI Loading End =========

;==================== Build Up GUI ========================
$MainGUI = GUICreate("Kabookie - Intra Messaging V 0.10b  -  Levix Edition", $width, $height, -1, -1, BitOr($WS_POPUP,$WS_MINIMIZEBOX), $WS_EX_LAYERED)

SetBitmap($MainGUI, $hImage, 0)

; Register notification messages
GUIRegisterMsg($WM_NCHITTEST, "WM_NCHITTEST")
GUISetState()
;WinSetOnTop($MainGUI, "", 1)
;fade in png background
For $i = 0 To 255 Step 1        ; The higher the Step the faster the fade in
    SetBitmap($MainGUI, $hImage, $i)
Next

; create child MDI gui window to hold controls
; this part could use some work - there is some flicker sometimes...
$controlGui = GUICreate("ControlGUI", $width, $height, 0, 0, $WS_POPUP, BitOR($WS_EX_LAYERED, $WS_EX_MDICHILD), $MainGUI)

; child window transparency is required to accomplish the full effect, so $WS_EX_LAYERED above, and
; I think the way this works is the transparent window color is based on the image you set here:
$GUIpic2 = GUICtrlCreatePic("", 0, 0, $width, $height)
;~ _ResourceSetImageToCtrl($GUIpic2, "GREY_1")
_ResourceSetImageToCtrl($GUIpic2, "KABOOKIE_PIC_1")
GUICtrlSetState(-1, $GUI_DISABLE)

$ConIPGroup = GUICtrlCreateGroup("", 650, 178, 205, 362)
GUICtrlSetFont(-1, 8.5,"Times New Roman")
GUICtrlSetBkColor(-1, $GUI_BKCOLOR_TRANSPARENT)
GUICtrlSetColor(-1, 0xFFFFFF)
$ConnectedIP = GUICtrlCreateListView("", 668, 196, 175, 292, BitOR($LVS_SORTASCENDING,$LVS_LIST,$LVS_SINGLESEL,$LVS_SHOWSELALWAYS,$WS_VSCROLL,$WS_BORDER))
_GUICtrlListView_SetColumnWidth($ConnectedIP, 0, 175)
GUICtrlSetFont(-1, 9,"Times New Roman")
GUICtrlSetColor(-1, 0x000000)
$EditIPBut = GUICtrlCreateButton("Edit", 782, 514, 61, 19)
GUICtrlSetState(-1, $GUI_DISABLE)

;~ ..........more controls added here...

GUISetState(@SW_SHOW)

Edited July 8, 2008 by Zedna

[inet]

Hmmm that did not work, i get a window the size of grey.gif, so my guess is that the pic's get mixed up.

Fading is not being done anymore too..

Edited July 8, 2008 by inet

[inet]

Hmmm that did not work, i get a window the size of grey.gif, so my guess is that the pic's get mixed up.

Fading is not being done anymore too..

Anyone has another solution or idea??

[Mojo]

Anyone has another solution or idea??

I had the same idea as you and tried to use Lod3n Launcher with resources.

For me the fading works, but the GUI on top with the Controls on it, is not transparent. (see attachment)

I couldn't find a quick fix and am now also hoping for help from Zedna.

As a work around we could include both pix as resources and filesave the grey.gif to temp folder before usage.

@ Zedna:

I'm wondering if _GDIPlus_ImageDispose($hImage) is still necessary if we use your function to get the handle, like this...

$hImage = _ResourceGetAsImage("PICTURE_BG_1") ??

thx

[ProgAndy]

To make the Top GUI transparent, use just this:

http://www.autoitscript.com/forum/index.ph...indowattributes

#include "WinAPI_SetLayered.au3"
GUISetBkColor(0x121314)
_WinAPI_SetLayeredWindowAttributes($transparent_gui, 0x121314)

-> No image needed

//Edit: And yes, you have to call _GDIPlus_ImageDispose

Edited July 28, 2008 by ProgAndy

[Mojo]

Hey mate, thanks a lot - works perfectly!

[ProgAndy]

I have a correction for _ResourceGetAsImage, but still doesn't work with animated gifs

expandcollapse popup

; returned hImage can be used in many GDI+ functions:
; $width =  _GDIPlus_ImageGetWidth ($hImage)
; $height = _GDIPlus_ImageGetHeight($hImage)
Func _ResourceGetAsImage($ResName, $ResType = 10, $DLL = -1) ; $RT_RCDATA = 10
    Local $ResData, $nSize, $hData, $pData, $pStream, $pBitmap, $hBitmap

    $ResData = _ResourceGet($ResName, $ResType, 0, $DLL)
    If @error Then Return SetError(1, 0, 0)
    $nSize = @extended

    _GDIPlus_Startup()

    If $ResType = $RT_BITMAP Then
        ; $ResData is hBitmap type
        $hImage = _GDIPlus_BitmapCreateFromHBITMAP($ResData)
    Else
        ; $ResData is memory pointer
        ; thanks ProgAndy
        $hData = _MemGlobalAlloc($nSize, 2)
        $pData = _MemGlobalLock($hData)
        _MemMoveMemory($ResData, $pData, $nSize)
        _MemGlobalUnlock($hData)
        $pStream = DllCall("ole32.dll", "int", "CreateStreamOnHGlobal", "int", $hData, "long", 1, "Int*", 0)
        $pStream = $pStream[3]
;~        _GDIPlus_Startup()
        $hImage = DllCall($ghGDIPDll, "int", "GdipCreateBitmapFromStream", "ptr", $pStream, "int*", 0)
        $hImage = $hImage[2]
        $hTempImg = DllCall($ghGDIPDll, "int", "GdipCloneImage","hwnd",$hImage,"int*",0)
        $hTempImg = $hTempImg[2]
        DllCall($ghGDIPDll, "int", "GdipImageForceValidation","hwnd",$hTempImg)
        _GDIPlus_BitmapDispose($hImage)
        $hImage = $hTempImg
;~          _GDIPlus_Shutdown()
        _WinAPI_DeleteObject($pStream)
        _MemGlobalFree($hData)
    EndIf

    Return $hImage ; hImage type
EndFunc   ;==>_ResourceGetAsImageoÝ÷ Ø   Ý#
.ØZ½æ§{^ȨÊ-«r¢çhm«Þ¶Þjw±µêçjPË-ú+y§!­ë(º·jëh×6Func _ResourceLoadDLL($DLL)
    Local $hInstance = DllCall("kernel32.dll", "int", "LoadLibraryEx", "str", $DLL,"hwnd",0,"dword",BitOR(0x00000020,0x00000002))
    If @error Or $hInstance[0] = 0 Then Return SetError(1,0,0)
    Return HWnd($hInstance[0])
EndFunc
Func _ResourceFreeDLL($DLLHandle)
    Local $aResult = DllCall("Kernel32.dll", "hwnd", "FreeLibrary", "hwnd", $DLLHandle)
    If @error Or $aResult[0] = 0 Then Return SetError(1,0,0)
    Return HWnd($aResult[0])
EndFuncoÝ÷ Ú)ÑzÊ.­ÇzÛaxÛ$Â+aÓ~,

in _ResourcePlaySound make similar additions

[Zedna]

I have a correction for _ResourceGetAsImage, but still doesn't work with animated gifs

I think your addition with $hTempImg is not neccessary. Animated GIFs from resources works fine when you comment this line at end of _ResourceGetAsImage()

_MemGlobalFree($hData)

But when I stop animation then Left/Right doesn't work and also unPause will not start animation again.

EDIT:  more clarification. Pause/unPause/Left/Right now works fine when I comment only this one line _MemGlobalFree($hData)

EDIT2: Here is link about using animated GIF images from resources: http://www.autoitscript.com/forum/index.ph...st&p=559985

Edited August 1, 2008 by Zedna

[smashly]

Have you tried using GdipLoadImageFromStream ?

[Zedna]

Have you tried using GdipLoadImageFromStream ?

Hey smashly that's great idea.

I will do some more tests.

Edited August 1, 2008 by Zedna

[ProgAndy]

I think your addition with $hTempImg is not neccessary. Animated GIFs from resources works fine when you comment this line at end of _ResourceGetAsImage()

_MemGlobalFree($hData)

OK I hope, that then all is cleaned up correctly. And what do you think about my other sugestion, the pre-loading of the DLLs?

//Edit: And, i cchenged from loadlibrary to loadlibraryEx, so that you can load as resourceFile, not as normal DLL,whose Functions are used (should be faster )

Edited August 1, 2008 by ProgAndy

[Zedna]

OK I hope, that then all is cleaned up correctly. And what do you think about my other sugestion, the pre-loading of the DLLs?

I'm afraid that this will cause memory leak but I will remove it (comment) in the next version though.

//Edit: And, i cchenged from loadlibrary to loadlibraryEx, so that you can load as resourceFile, not as normal DLL,whose Functions are used (should be faster )

It looks good as for optimizations.

I will look into it more deeply later. As obvious thanks for your neverending cooperation ProgAndy

Edited August 1, 2008 by Zedna

[ProgAndy]

It looks good as for optimizations.

I will look into it more deeply later. As obvious thanks for your neverending cooperation ProgAndy

Thanks But why should I write my own reource UDf, when this is great. ( I would only have stolen you code )

[Zedna]

Thanks But why should I write my own reource UDf, when this is great. ( I would only have stolen you code )

I will add your additions but I'm not so quick as you :-)

And don't be worried about "stolen code" my UDF is free for any purposes

[ProgAndy]

I found a bug You should remove _GDIPlus_Startup() from the Image-Functions, or at least add _GDIPlus_Shutdown(), because GDIPlus only can be shut down correctly, if _GDIPlus_Shutdown() is called as often as _GDIPlus_Startup()

[Zedna]

I found a bug You should remove _GDIPlus_Startup() from the Image-Functions, or at least add _GDIPlus_Shutdown(), because GDIPlus only can be shut down correctly, if _GDIPlus_Shutdown() is called as often as _GDIPlus_Startup()

As I said in my first post (known problems) I did it but then some things stopped working :-(

Now I think I will add  _GDIPlus_Startup() at begin of my whole UDF so it will start GDI+ once at begin of script which will be including my resources UDF and no _GDIPlus_Shutdown() will be done at all.

[Zedna]

New version. See first post.

TODO list:

- add _ResourceLoadDLL(),_ResourceFreeDLL() - thanks ProgAndy

2008-08-14

- change: _GDIPlus_Startup() is called once at start of whole include --> no _GDIPlus_Shutdown() is called

- fixed support for animated GIFs in _ResourceGetAsImage() --> removed _MemGlobalFree($hData)

- used simpler UDF syntax (from WinAPI) instead of DllCall() where possible

- added new example for animated GIF image

[Will66]

Possible to support flash(.swf)?

[Zedna]

Possible to support flash(.swf)?

Post your working/simple example using SWF.

I will look at it.

But I think it will not be any simple way for this.
