Transparent background for slider element

[Skdp]

Hello, I am trying to set a transparent background to the GUICtrlCreateSlider elements to show the main background. Is it possible?

#include <SliderConstants.au3>
#include <GUIConstantsEx.au3>

Example()

Func Example()

    Local $Form = GUICreate("Example GUI", 449, 211)

    GUICtrlCreatePic(@ScriptDir & '\bg.bmp', 0, 0, 0, 0)
    GUICtrlSetState(-1, $GUI_DISABLE)

    Local $Slider = GUICtrlCreateSlider(0, 0, 399, 50)

    Local $Slider_Vert = GUICtrlCreateSlider(399, 0, 50, 211, $TBS_VERT)

    GUISetState(@SW_SHOW)

    While 1
        $nMsg = GUIGetMsg()
        Switch $nMsg
            Case $GUI_EVENT_CLOSE
                Exit

        EndSwitch
    WEnd

EndFunc




Edited 11 hours ago by Skdp

[Nine]

Yes it is possible but you would need to create multiple GUIs like this :

#include <GUIConstants.au3>
#include <Constants.au3>
#include <WinAPISysWin.au3>

Opt("MustDeclareVars", True)

Example()

Func Example()
  Local $hForm = GUICreate("Example GUI", 429, 211)
  GUICtrlCreatePic(@ScriptDir & '\bg.bmp', 0, 0, 0, 0)
  GUICtrlSetState(-1, $GUI_DISABLE)
  GUISetState()

  Local $hGUI1 = GUICreate("", 379, 50, 0, 0, $WS_POPUP, $WS_EX_LAYERED + $WS_EX_MDICHILD, $hForm)
  Local $Slider = GUICtrlCreateSlider(0, 0, 379, 50)
  GUICtrlSetBkColor(-1, 0xC0FFEE)
  GUISetState()
  _WinAPI_SetLayeredWindowAttributes($hGUI1, 0xC0FFEE)

  Local $hGUI2 = GUICreate("", 50, 211, 379, 0, $WS_POPUP, $WS_EX_LAYERED + $WS_EX_MDICHILD, $hForm)
  Local $Slider_Vert = GUICtrlCreateSlider(0, 0, 50, 211, $TBS_VERT)
  GUICtrlSetBkColor(-1, 0xC0FFEE)
  GUISetState()
  _WinAPI_SetLayeredWindowAttributes($hGUI2, 0xC0FFEE)

  While True
    Switch GUIGetMsg()
      Case $GUI_EVENT_CLOSE
        Exit
    EndSwitch
  WEnd
EndFunc   ;==>Example



Edited 9 hours ago by Nine
