Rotating Transparent Image Unclear

[NassauSky]

I will be using some images similar to the one I have attached to this post, which isn't the clearest, so it would be nice to have a better rendering on the PC's

Here is the slightly modified following code I'm using. Thanks @UEZ!  What can I do to increase the clarity since the example image is very pixelated yet it shows up much clearer in other code? I'll provide another example if needed.

BTW I left in a white slightly shaded oval in that image that you might not see until it's rendered using the code below.

expandcollapse popup

#include <WindowsConstants.au3>
#include <WinAPISysWin.au3>
#include <GDIPlus.au3>
Opt("GUIOnEventMode", 1)

Global Const $width = 600
Global Const $height = 600
_GDIPlus_Startup()

Global $ghGDIPDll = DllOpen("gdiplus.dll") ; Open GDI+ DLL

Local $IMAGE_PATH = @ScriptDir & "\TransparentImageOverlay.png"
If Not FileExists($IMAGE_PATH) Then
    MsgBox(($MB_SYSTEMMODAL + $MB_ICONHAND), "", $IMAGE_PATH & " not found!", 30)
    Exit
EndIf
$g_hImage = _GDIPlus_ImageLoadFromFile($IMAGE_PATH)
$hBG_Bitmap = $g_hImage

Global $hWnd = GUICreate("GDI+: Example by UEZ 2010", $width, $height, -1, -1, 0, $WS_EX_LAYERED + $WS_EX_TOOLWINDOW)
GUISetOnEvent(-3, "_Exit")
GUISetState()

Global $hGraphics = _GDIPlus_GraphicsCreateFromHWND($hWnd)
Global $hBitmap = _GDIPlus_BitmapCreateFromGraphics($width, $height, $hGraphics) ; AI recommends a 4th param 32-bit ARGB bitmap to be higher res
Global $hBackbuffer = _GDIPlus_ImageGetGraphicsContext($hBitmap)

; Set up transparency
Global $alpha = 255 ; Full opacity
Global $tBlend = DllStructCreate($tagBLENDFUNCTION)
Global $pBlend = DllStructGetPtr($tBlend) ; Declare $pBlend and get its pointer
DllStructSetData($tBlend, "Alpha", $alpha)
DllStructSetData($tBlend, "Format", 1)

#Region Make GUI transparent
$ScreenDc = _WinAPI_GetDC($hWnd)
$GDIBitmap = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hBitmap)
$dc = _WinAPI_CreateCompatibleDC($ScreenDc)
_WinAPI_SelectObject($dc, $GDIBitmap)
$tSize = DllStructCreate($tagSIZE)
$pSize = DllStructGetPtr($tSize)
DllStructSetData($tSize, "X", $width)
DllStructSetData($tSize, "Y", $height)
$tSource = DllStructCreate($tagPOINT)
$pSource = DllStructGetPtr($tSource)
$tPoint = DllStructCreate($tagPOINT)
$pPoint = DllStructGetPtr($tPoint)
DllStructSetData($tPoint, "X", 0)
DllStructSetData($tPoint, "Y", 0)
#EndRegion

Global $hMatrix = _GDIPlus_MatrixCreate()
Global $rot_mid_x = $width / 2
Global $rot_mid_y = $height / 2
_GDIPlus_MatrixTranslate($hMatrix, $rot_mid_x, $rot_mid_y)

Local $iAngle = 10

While Sleep(50)
    _GDIPlus_GraphicsClear($hBackbuffer, 0xFF000000) ; Clear with opaque black color

    _GDIPlus_MatrixRotate($hMatrix, $iAngle, "False")
    _GDIPlus_GraphicsSetTransform($hBackbuffer, $hMatrix)
    _GDIPlus_GraphicsDrawImageRect($hBackbuffer, $hBG_Bitmap, -$rot_mid_x / 2, -$rot_mid_y / 2, $width / 2, $height / 2)
    ;_GDIPlus_GraphicsDrawImageRect($hBackbuffer, $hBG_Bitmap, -$aFittingRect[0]/2, -$aFittingRect[1]/2, $aFittingRect[0], $aFittingRect[1])

    $GDIBitmap = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hBitmap)
    _WinAPI_SelectObject($dc, $GDIBitmap)
    _WinAPI_UpdateLayeredWindow($hWnd, $ScreenDc, 0, $pSize, $dc, $pSource, 0, $pBlend, 1)
    _WinAPI_DeleteObject($GDIBitmap)
WEnd

Func _Exit()
    _WinAPI_DeleteDC($dc)
    _WinAPI_ReleaseDC($hWnd, $ScreenDc)
    _GDIPlus_BitmapDispose($hBitmap)
    _GDIPlus_GraphicsDispose($hBackbuffer)
    _GDIPlus_MatrixDispose($hMatrix)
    _GDIPlus_BitmapDispose($hBitmap)
    _GDIPlus_GraphicsDispose($hBackbuffer)
    _GDIPlus_GraphicsDispose($hGraphics)
    _GDIPlus_Shutdown()
    DllClose($ghGDIPDll) ; Close GDI+ DLL
    Exit
EndFunc



Edited May 4 by NassauSky

[UEZ]

The problem is that the image is semi-transparent and thus it looks good on white background. If you change the bg to black the result is the same as in your code.

I don't have an idee yet how to display it with white bg but in a transparent GUI.

Edit:

If your bg is light then you can use:

While Sleep(10)
    _GDIPlus_GraphicsClear($hBackbuffer, 0) ; Clear with opaque black color

    _GDIPlus_MatrixRotate($hMatrix, $iAngle, "False")
    _GDIPlus_GraphicsSetTransform($hBackbuffer, $hMatrix)
    _GDIPlus_GraphicsDrawImageRect($hBackbuffer, $hBG_Bitmap, -$rot_mid_x / 2, -$rot_mid_y / 2, $width / 2, $height / 2)

    $GDIBitmap = _GDIPlus_BitmapCreateHBITMAPFromBitmap($hBitmap, 0xFFFFFFFF)
    _WinAPI_SelectObject($dc, $GDIBitmap)
    _WinAPI_UpdateLayeredWindow($hWnd, $ScreenDc, 0, $pSize, $dc, $pSource, 0xFFFFFFFF, $pBlend, 1)
    _WinAPI_DeleteObject($GDIBitmap)
WEnd

which will add white as a bg color.

Edited May 5 by UEZ

[NassauSky]

Thanks @UEZ that's a good thing to know!

That will do the trick for certain images that will take too long to modify.

If anyone else ever finds an idea how to work with semitransparent PNG files to display with the semi transparent effect I'd love to know. 🙂



Edited May 5 by NassauSky
