[issue] autoit high dpi blurriness, fuzziness in gui

[simplercoder000]

Hi there,

I'm facing this issue where my GUI app gets blurriness/fuzziness controls.

My screen size are big so I'm enforced to up-scale my display text to 150% so I can view things normally.



The same issue has been reported as bug here: https://www.autoitscript.com/trac/autoit/ticket/3238

But this issue seems like still unsolved until today.



I have been searching in the forum for a while, and I have found this:



I have tried this script, but I'm still facing the same issue.

I have even tried adding the High DPI feature into my script but that's also didn't work

#AutoIt3Wrapper_Res_HiDpi



Example GUI:

Quote

#include <ButtonConstants.au3>
#include <EditConstants.au3>
#include <GUIConstantsEx.au3>
#include <StaticConstants.au3>
#include <WindowsConstants.au3>
#Region ### START Koda GUI section ### Form=
$Form1 = GUICreate("Form1", 220, 172, 195, 124)
$Button1 = GUICtrlCreateButton("Button1", 32, 112, 75, 33)
$Button2 = GUICtrlCreateButton("Button2", 114, 112, 75, 33)
$Input1 = GUICtrlCreateInput("Input1", 48, 72, 121, 21)
$Label1 = GUICtrlCreateLabel("Autoit are awesome !", 64, 24, 103, 17)
GUISetState(@SW_SHOW)
#EndRegion ### END Koda GUI section ###

While 1
    $nMsg = GUIGetMsg()
    Switch $nMsg
        Case $GUI_EVENT_CLOSE
            Exit

    EndSwitch
WEnd

I'm running on Windows 7 x64

[argumentum]

Welcome to the forum.
Take a look at https://www.autoitscript.com/forum/index.php?showtopic=210613





Edited February 13, 2024 by argumentum

[simplercoder000]

1 hour ago, argumentum said:

Take a look at https://www.autoitscript.com/forum/index.php?showtopic=210613

I don't know how did I miss this thread, maybe I haven't search well, thank you!



The High DPI issue must be treated as serious problem since not all users have the same screen sizes.

I say this because I even notice that some internal AutoIt tools like Koda (Form Designer) or AutoIt3Wrapper GUI has the HiDPI issues.

[argumentum]

before you settle for what you've found, please try

and let me know. Thanks

[simplercoder000]

@argumentum

Here's my result:

Added 60 items to the list
Screen Dimensions: 1280 x 800
Listview Dimensions: 19382 x 19
Calculated GUI size: 640 x 360
OS: WIN_7



[argumentum]

...but how does it look ?, the code in the 1st post.

[argumentum]

for example, this is the way it looks in each of my 2 monitors:

placed one on top of the other. 100% and 225%. Even if you have one in Win7.

And, sorry, I meant the one here at this post ( https://www.autoitscript.com/forum/topic/210604-tester-needed/#comment-1522028 ) not the first one. My bad.



Edited February 13, 2024 by argumentum
better pic

[simplercoder000]

8 minutes ago, argumentum said:

...but how does it look ?, the code in the 1st post.

I have attached a screenshot in the thread you mentioned:

[argumentum]

1 minute ago, argumentum said:

I meant the one here at this post ( https://www.autoitscript.com/forum/topic/210604-tester-needed/#comment-1522028 ) not the first one. My bad.



[simplercoder000]

@argumentum

I tried it and doesn't shows any GUI windows.

The output also doesn't prints any errors.

[argumentum]

ok then. Your solution was the best for your setup, that unfortunately I don't have ( one of those ) to try out. Thanks @simplercoder000

[simplercoder000]

I have solved the issue by combining HiDPI_Changes.au3 UDF by @Jos with @InnI method to get current value of DPI

That resulted in getting a correctly working GUI with High DPI support and without any issues.

For more info please check here:



Thanks @argumentum for helping me.
