Is it possible to simulate a dual-projector slide show using AutoIt?

[timmy2]

To save future readers a little sweat I'm editing my original post to insert the following:

After trying various suggested scripting approaches, some of which introduced new problems and some which had the same problem described here, I tried my script and a few others on another computer. No white flashes, tears, glitches. So I brought it back to my main box and disabled the Intel GPU that was feeding a 3rd monitor. Down to two monitors connected to a single NVidia GPU the visual glitches disappeared. Who would'a thought?!

That said, some of the replies that follow provide valuable insights into the various ways to skin this cat using AutoIt.  Some suggested scripts introduced new problems so they might be instructive about approaches to avoid. Ultimately, JohnOne suggested an elegantly simple script that perfectly accomplishes my goal.

---------------------

I want to display a  800x600 picture (i.e., not full-screen) without a border, close-box, title, etc.  I then want to replace that picture with another one -- cleanly. Think of an old-fashioned dual-projector slide show where there's no black-out or other interruption to the image on screen. This way I can start with a background image, then add elements to it seamlessly (once called "a build", i.e., pseudo-animation).  The image format doesn't matter to me.

I can't use an animated GIF or video because my code is doing things in the background between images, so timing varies.

I'm having bad luck using an AutoIt form to accomplish this (GUICtrlCreatePic, followed by subsequent GUICtrlSetImage's).  The result is a glitch -- usually a white flash or tear in the picture -- at almost every image change. (see 10/10/13 post entitled "random visual glitch when using GUICtrlSetImage"). So I guess that's out.

SplashImageOn  blanks out the first image before displaying the next (like a single-projector slide show), so it's not seamless -- plus there's still a tiny border visible.

$var = Default

SplashImageOn("","image1.bmp",$var,$var,$var,$var,1)
sleep(2000)
SplashImageOn("","image2.bmp",$var,$var,$var,$var,1)
sleep(2000)
SplashImageOn("","image3.bmp",$var,$var,$var,$var,1)
sleep(2000)

Any suggestions?

Edited October 12, 2013 by timmy2

[kaotkbliss]

Have you tried using a borderless gui? I'm pretty sure images can be loaded and layered using GDI+

[timmy2]

Have you tried using a borderless gui? I'm pretty sure images can be loaded and layered using GDI+



Thank you for replying, kaotkbliss.

Could you give me a simple example?   As I mentioned in my original post I've tried GuiCreate/GuiCtrlCreatePic/GuiCtrlSetImage but every GuiCtrlSetImage causes a tear/white flash in the image area -- so it's not clean.

Maybe "GDI+" is different but I wouldn't know which "_GDIPlus..." commands would be applicable. Moreover, the help file seems a bit cryptic in this area. For example, "_GDIPlus_BitmapCreateFromFile" might be useful but I see no mention of options to make the GUI borderless, and the included example is rather complex and deals with saving a screen capture in a typical gui box.

Plus, I'm concerned that I could pursue trying to learn enough about GDI+ to replace what I did (see below) using the aforementioned GUI commands and end up discovering the result has similar problems.  I'm really surprised GUICtrlSetImage can't display an image over an existing one without tearing.

$form=GUICreate("Test",900,530,518,272, BitOR($WS_SYSMENU,$WS_POPUP), 0)
$cid=GUICtrlCreatePic(@ScriptDir & "\imagebackground.bmp", 0,0, 900, 530)
GuiCtrlSetState($cid,$GUI_DISABLE)

$PSimage=GUICtrlCreatePic(@ScriptDir & "\image1.bmp", 0,0,900,530)

GUISetState(@SW_SHOW)  ;show 1st image
MsgBox(0,"","test")    ;simulate doing some background business before next image is displayed

GUICtrlSetImage($PSimage, @ScriptDir & "\image2.bmp") ;show 2nd image
MsgBox(0,"","test")

GUICtrlSetImage($PSimage,@ScriptDir & "\image3.bmp")  ;show 3rd image
MsgBox(0,"","test")

GUICtrlSetImage($PSimage,@ScriptDir & "\image4.bmp")  'show 4th image
MsgBox(0,"","test")

Exit

Edited October 11, 2013 by timmy2

[UEZ]

Maybe slideshow gdiplus.

Br,

UEZ

[kaotkbliss]

Also it might work better in a gui instead of splash, look into popup and borderless (can't remember the exact combination off hand but there's tons of examples here in the forums) styles for the guicreate options. Also, you can make the gui completely transparent if you have any troubles with edges

[BrewManNH]

You're probably thinking of the $WS_POPUP style for the GUI?

[JohnOne]

First thing I'd try is a pile of controls over each other, delete them as you go along.

[willichan]

 Why not actually do it the way a two projector setup would.

Load slide 1 in projector 1

turn on projector 1 lamp

load slide 2 in projector 2

wait for slide advance

turn on projector 2 lamp

turn off projector 1 lamp

load slide 3 in projector 1

wait for slide advance

etc...

#include <WindowsConstants.au3>

$form=GUICreate("Test",900,530,518,272, BitOR($WS_SYSMENU,$WS_POPUP), 0)

$PSimage1=GUICtrlCreatePic(@ScriptDir & "\image1.bmp", 0,0,900,530) ;load slide 1 for 'projector' 1
GUICtrlSetState($PSimage1, @SW_SHOW) ;show 'projector' 1

GUISetState(@SW_SHOW, $form) ; start showing it

$PSimage2=GUICtrlCreatePic(@ScriptDir & "\image2.bmp", 0,0,900,530) ;load slide 2 for 'projector' 2
GUICtrlSetState($PSimage1, @SW_HIDE) ;hide 'projector' 2

MsgBox(0, "slideshow", "slide 1") ;wait for slide advance

GUICtrlSetState($PSimage2, @SW_SHOW) ;show 'projector' 2
GUICtrlSetState($PSimage1, @SW_HIDE) ;hide 'projector' 1
GUICtrlSetImage($PSimage1,@ScriptDir & "\image3.bmp") ;load slide 3 for 'projector; 1

MsgBox(0, "slideshow", "slide 2") ;wait for slide advance

GUICtrlSetState($PSimage1, @SW_SHOW) ;show 'projector' 1
GUICtrlSetState($PSimage2, @SW_HIDE) ;hide 'projector' 2
GUICtrlSetImage($PSimage2,@ScriptDir & "\image4.bmp") ;load slide 4 for 'projector; 2

MsgBox(0, "slideshow", "slide 3") ;wait for slide advance

GUICtrlSetState($PSimage2, @SW_SHOW) ;show 'projector' 2
GUICtrlSetState($PSimage1, @SW_HIDE) ;hide 'projector' 1
;GUICtrlSetImage($PSimage1,@ScriptDir & "\image5.bmp") ;load slide 5 for 'projector; 1

MsgBox(0, "slideshow", "slide 4") ;wait for slide advance

Exit

No flash on my system when I tested it.

Edited October 12, 2013 by willichan

[timmy2]

Thank you for the comprehensive reply!

The only problem with your script is that image3.jpg doesn't display. I've stared at the script for 15 minutes and feel like an idiot because your script is so simple and makes perfect sense, yet image4.jpg appears for "Slide 3" and for "Slide 4".  I've attached the sample images (jpeg's to keep file sizes small).  I did a search/replace in your script to replace .bmp with .jpg. Please try running this script with my images and tell me if you get the same result.  And, thank you again.

#include <WindowsConstants.au3>

$form=GUICreate("Test",900,530,518,272, BitOR($WS_SYSMENU,$WS_POPUP), 0)

$PSimage1=GUICtrlCreatePic(@ScriptDir & "\image1.jpg", 0,0,900,530) ;load slide 1 for 'projector' 1
GUICtrlSetState($PSimage1, @SW_SHOW) ;show 'projector' 1

GUISetState(@SW_SHOW, $form) ; start showing it

$PSimage2=GUICtrlCreatePic(@ScriptDir & "\image2.jpg", 0,0,900,530) ;load slide 2 for 'projector' 2
GUICtrlSetState($PSimage1, @SW_HIDE) ;hide 'projector' 2

MsgBox(0, "slideshow", "slide 1") ;wait for slide advance

GUICtrlSetState($PSimage2, @SW_SHOW) ;show 'projector' 2
GUICtrlSetState($PSimage1, @SW_HIDE) ;hide 'projector' 1
GUICtrlSetImage($PSimage1,@ScriptDir & "\image3.jpg") ;load slide 3 for 'projector; 1

MsgBox(0, "slideshow", "slide 2") ;wait for slide advance

GUICtrlSetState($PSimage1, @SW_SHOW) ;show 'projector' 1
GUICtrlSetState($PSimage2, @SW_HIDE) ;hide 'projector' 2
GUICtrlSetImage($PSimage2,@ScriptDir & "\image4.jpg") ;load slide 4 for 'projector; 2

MsgBox(0, "slideshow", "slide 3") ;wait for slide advance

GUICtrlSetState($PSimage2, @SW_SHOW) ;show 'projector' 2
GUICtrlSetState($PSimage1, @SW_HIDE) ;hide 'projector' 1
;GUICtrlSetImage($PSimage1,@ScriptDir & "\image5.jpg") ;load slide 5 for 'projector; 1

MsgBox(0, "slideshow", "slide 4") ;wait for slide advance

Exit

[JohnOne]

#include <WindowsConstants.au3>

$form=GUICreate("Test",900,530,518,272, BitOR($WS_SYSMENU,$WS_POPUP), 0)

$PSimage4=GUICtrlCreatePic(@ScriptDir & "\image4.jpg", 0,0,900,530) ;load slide 1 for 'projector' 1
$PSimage3=GUICtrlCreatePic(@ScriptDir & "\image3.jpg", 0,0,900,530)
$PSimage2=GUICtrlCreatePic(@ScriptDir & "\image2.jpg", 0,0,900,530)
$PSimage1=GUICtrlCreatePic(@ScriptDir & "\image1.jpg", 0,0,900,530)
GUISetState(@SW_SHOW, $form) ; start showing it

MsgBox(0, "slideshow", "slide 1") ;wait for slide advance
GUICtrlDelete($PSimage1)

MsgBox(0, "slideshow", "slide 2") ;wait for slide advance
GUICtrlDelete($PSimage2)

MsgBox(0, "slideshow", "slide 3") ;wait for slide advance
GUICtrlDelete($PSimage3)

MsgBox(0, "slideshow", "slide 4") ;wait for slide advance

[DatMCEyeBall]

@JohnOne - cleaner way of doing it:

#include <WindowsConstants.au3>

$form = GUICreate("Test", 900, 530, 518, 272, BitOR($WS_SYSMENU, $WS_POPUP), 0)

Global $PSimages[4]
For $i = UBound($PSimages) - 1 To 0 Step -1
    $PSimages[$i] = GUICtrlCreatePic(@ScriptDir & "\image" & $i + 1 & ".jpg", 0, 0, 900, 530)
Next
GUISetState(@SW_SHOW, $form) ; start showing it

For $i = 0 To UBound($PSimages) - 1
    MsgBox(0, "slideshow", "slide " & $i + 1) ;wait for slide advance
    GUICtrlDelete($PSimages[$i])
Next

Edited October 12, 2013 by DatMCEyeBall

[JohnOne]

Was thinking about that, just couldn't be bothered, good exercise for OP.

[DatMCEyeBall]

He might resort to ruthless copy-paste

[willichan]

Pre-loading all of the images works well if there are only a small set, but if the slideshow has a lot of images, you will be using more memory that you may want to.

@timmy2:  I'll take a look at it.

[timmy2]

datmc result.zip

Thank you DatMCEyeBall and John One.  Using the jpegs I provided previously both of your scripts work with rarely a glitch (the exception being an occasional white flash before the first image ).

BUT... when I substitute my actual photographs, or even slightly more demanding images, problems become visible.  (Note that my Windows 8 background is a solid color: 80,80,80, in case that's a factor.)

DatMCEyeBall's script exhibits three problems:

1. the occasional white flash or tear before the first image, between images, and after the last image. See the attached Camtasia recording.

2. with the attached images you see all four images briefly load at the start

3. as you click through them you see a brief preview of the slide that will follow. I'll have to describe this issue because I couldn't capture it with Camtasia:  run the script, click OK on the first msg box, after that you'll see "Image 3" appear briefly followed by the desired "Image 2".  Likewise, "Image 4" appears briefly before "Image 3". This suggests that JohnOne's idea of loading up all four images ("controls") and removing them one by one allows controls underneath to briefly appear at each slide change.

I hope you don't take the foregoing as criticism; I created this post because I couldn't avoid the glitches between images with my code so I figured folks here with far more experience would know the secret recipe.  For me to try to learn GDI+ as one contributor suggested is daunting if it's just going to end up yielding the same problems, so I greatly appreciate the example code DatMCEyeBall and JohnOne provided.

Come to think of it, I should try this on another computer. The one I'm working on, albeit a zippy SSD-based 32GB I7-3770 with 3 monitors, is using a combination of an Nvidia card for two monitors and the built-in Intel GPU for the one that the script is running on. I'll try it on another less complicated rig and report back.(But since Camtasia captures the flashes I suspect these problems are hardware independent.)

Edited October 12, 2013 by timmy2

[JohnOne]

Try this ex style

#include <WindowsConstants.au3>
#include <GUIConstantsEx.au3>


$form=GUICreate("Test",900,530,518,272,BitOR($WS_SYSMENU,$WS_POPUP),$WS_EX_COMPOSITED)


$PSimage=GUICtrlCreatePic(@ScriptDir & "\image1.jpg", 0,0,900,530)
GUISetState(@SW_SHOW)
MsgBox(0,"","test")

GUICtrlSetImage($PSimage, @ScriptDir & "\image2.jpg")
MsgBox(0,"","test")

GUICtrlSetImage($PSimage,@ScriptDir & "\image3.jpg")
MsgBox(0,"","test")

GUICtrlSetImage($PSimage,@ScriptDir & "\image4.jpg")
MsgBox(0,"","test")

[timmy2]



Try this ex style

#include <WindowsConstants.au3>
#include <GUIConstantsEx.au3>


$form=GUICreate("Test",900,530,518,272,BitOR($WS_SYSMENU,$WS_POPUP),$WS_EX_COMPOSITED)


$PSimage=GUICtrlCreatePic(@ScriptDir & "\image1.jpg", 0,0,900,530)
GUISetState(@SW_SHOW)
MsgBox(0,"","test")

GUICtrlSetImage($PSimage, @ScriptDir & "\image2.jpg")
MsgBox(0,"","test")

GUICtrlSetImage($PSimage,@ScriptDir & "\image3.jpg")
MsgBox(0,"","test")

GUICtrlSetImage($PSimage,@ScriptDir & "\image4.jpg")
MsgBox(0,"","test")



Magnifique!  Seamless display of my actual images as well as all test images. No artifacts. No flashes. Nada.  Thank you, JohnOne! (would it help other readers for you to explain in simple terms why the "GUI double buffering" solved the problems -- if indeed that was the sole solution?)

Edited October 12, 2013 by timmy2

[JohnOne]

No Idea sorry.

I've just read before that when people have problems with flickering in GUI, it usually solves the problem.

Maybe an <cough> autoit elder might step up.
