Help with transparent pic

[mage123]

I have a gui that uses gdi+ with a transparent png in it. I also made a blank pic control behind the png so that I could use GUIGetCursorInfo to see if you are hovering over it, and if so draw a different image on top (hover over image). It works fine, except that the png isn't square, so it displays the hover over image even when you're not hovering over it. Also, I use GUICtrlSetCursor to make a hand cursor show whenever you hover over it, and it has the same problem- displaying the hand even when you aren't hovering over the image. Anybody know how to fix this?

[martin]

I have a gui that uses gdi+ with a transparent png in it. I also made a blank pic control behind the png so that I could use GUIGetCursorInfo to see if you are hovering over it, and if so draw a different image on top (hover over image). It works fine, except that the png isn't square, so it displays the hover over image even when you're not hovering over it. Also, I use GUICtrlSetCursor to make a hand cursor show whenever you hover over it, and it has the same problem- displaying the hand even when you aren't hovering over the image. Anybody know how to fix this?

Malkey has some functions in example scripts that allow you to decide if a point, the cursor in your case, is inside a shape. So instaed of deciding if you are over the image you could decide if you were inside a certain area of the image.

You'll have to search for the functions because I don't have a link.

[AdmiralAlkex]

You'll have to search for the functions because I don't have a link.

Link.

[mage123]

I would rather not make a shape to see if the cursor is in it... Do you know if there's a function to read the pixel of an image or graphics object?

[Yashied]

Try to determine a transparent areas in PNG.

#Include <GDIP.au3>

If BitAND(_GDIPlus_BitmapGetPixel($hImage, $iX, $iY), 0xFF000000) Then
    ; Set over image
EndIf

GDIP UDF

Edited October 5, 2010 by Yashied

[Yashied]

expandcollapse popup

#Include <GDIPlus.au3>
#Include <WinAPIEx.au3>
#Include <WindowsConstants.au3>

_GDIPlus_Startup()

$hBackground = _GDIPlus_ImageLoadFromFile(@ScriptDir & '\bg_440x440.png')
$hReg = _GDIPlus_ImageLoadFromFile(@ScriptDir & '\Red.png')
$hYellow = _GDIPlus_ImageLoadFromFile(@ScriptDir & '\Yellow.png')

$State = Default

$hForm = GUICreate('', 440, 440, -1, -1, $WS_POPUPWINDOW, BitOR($WS_EX_LAYERED, $WS_EX_TOPMOST))
_Update(0)
GUISetState()


While 1
    $Info = GUIGetCursorInfo($hForm)
    If @error Then
        _Update(0)
    Else
        If ($Info[0] >=120) And ($Info[0] <=320) And ($Info[1] >=120) And ($Info[1] <=320) And (BitAND(_GDIPlus_BitmapGetPixel($hReg, $Info[0] - 120, $Info[1] - 120), 0xFF000000) = 0xFF000000) Then
            _Update(1)
            If $Info[2] Then
                ExitLoop
            EndIf
        Else
            _Update(0)
        EndIf
    EndIf
    $Msg = GUIGetMsg()
    Switch $Msg
        Case -3
            ExitLoop
    EndSwitch
WEnd

_GDIPlus_Shutdown()

Func _Update($iState)

    If $iState = $State Then
        Return
    EndIf

    Local $hGraphic, $hImage

    $hImage = _GDIPlus_ImageClone($hBackground)
    $hGraphic = _GDIPlus_ImageGetGraphicsContext($hImage)
    Switch $iState
        Case 0
            _GDIPlus_GraphicsDrawImageRect($hGraphic, $hYellow, 120, 120, 200, 200)
        Case 1
            _GDIPlus_GraphicsDrawImageRect($hGraphic, $hReg, 120, 120, 200, 200)
    EndSwitch
    _WinAPI_UpdateLayeredWindowEx($hForm, _GDIPlus_BitmapCreateHBITMAPFromBitmap($hImage), 255, 1)
    _GDIPlus_GraphicsDispose($hGraphic)
    _GDIPlus_ImageDispose($hImage)
    $State = $iState
EndFunc   ;==>_Update

Func _GDIPlus_BitmapGetPixel($hBitmap, $iX, $iY)

    Local $aResult = DllCall($ghGDIPDll, 'uint', 'GdipBitmapGetPixel', 'ptr', $hBitmap, 'int', $iX, 'int', $iY, 'ptr*', 0)

    If @error Then
        Return SetError(1, 0, 0)
    Else
        If $aResult[0] Then
            Return SetError($aResult[0], 0, 0)
        EndIf
    EndIf
    Return $aResult[4]
EndFunc   ;==>_GDIPlus_BitmapGetPixel

Func _GDIPlus_ImageClone($hImage)

    Local $aResult = DllCall($ghGDIPDll, 'uint', 'GdipCloneImage', 'ptr', $hImage, 'ptr*', 0)

    If @error Then
        Return SetError(1, 0, 0)
    Else
        If $aResult[0] Then
            Return SetError($aResult[0], 0, 0)
        EndIf
    EndIf
    Return $aResult[2]
EndFunc   ;==>_GDIPlus_ImageClone

WinAPIEx.au3

Edited October 5, 2010 by Yashied

[UEZ]

Another possibility: instead checking for transparency you can calculate the distance from the middle of the buttom to its border.

In this case (round objects with same diameter) it is the radius. That means when the mouse distance to the middle of the buttom is less then

the radius then change the image.

Example (images used from pevious post by Yashied):

expandcollapse popup

#include <GDIPlus.au3>
#include <GUIConstantsEx.au3>
#include <WindowsConstants.au3>
#include <WinAPIEx.au3>
Opt("MustDeclareVars", 1)
Opt("GUIOnEventMode", 1)

_GDIPlus_Startup()

Local $hBackground = _GDIPlus_ImageLoadFromFile("bg_440x440.png")
Local $Width = _GDIPlus_ImageGetWidth($hBackground)
Local $Height = _GDIPlus_ImageGetHeight($hBackground)

Local $center_w = $Width / 2
Local $center_h = $Height / 2

Local $hRed = _GDIPlus_ImageLoadFromFile("Red.png")
Local $hRed_w = _GDIPlus_ImageGetWidth($hRed)
Local $hRed_h = _GDIPlus_ImageGetHeight($hRed)

Local $hYellow = _GDIPlus_ImageLoadFromFile("Yellow.png")
Local $hYellow_w = _GDIPlus_ImageGetWidth($hYellow)
Local $hYellow_h = _GDIPlus_ImageGetHeight($hYellow)

Local $hGUI = GUICreate("GDI+ Mouse Hover by UEZ", $Width, $Height, -1, -1, $WS_POPUP, BitOR($WS_EX_LAYERED, $WS_EX_TOPMOST))
GUISetState()

Local $hGraphics = _GDIPlus_GraphicsCreateFromHWND($hGUI)
Local $hBitmap = _GDIPlus_BitmapCreateFromGraphics($Width, $Height, $hGraphics)
Local $hBackbuffer = _GDIPlus_ImageGetGraphicsContext($hBitmap)

GUIRegisterMsg($WM_NCHITTEST, "WM_NCHITTEST")
GUISetOnEvent($GUI_EVENT_CLOSE, "_Exit")

Local $mpos, $pd, $radius = ($hYellow_w - 22) / 2

While Sleep(30)
    _GDIPlus_GraphicsClear($hBackbuffer, 0x00000000)
    _GDIPlus_GraphicsDrawImageRect($hBackbuffer, $hBackground, 0, 0, $Width, $Height)

    $mpos = GUIGetCursorInfo($hGUI)
    $pd = Pixel_Distance($mpos[0], $mpos[1], $center_w, $center_h)
    If $mpos[2] And $pd < $radius Then _Exit()
    If $pd < $radius Then
        _GDIPlus_GraphicsDrawImage($hBackbuffer, $hRed, $Width / 2 - $hRed_w / 1.5, $Height / 2 - $hRed_w / 1.5)
    Else
        _GDIPlus_GraphicsDrawImage($hBackbuffer, $hYellow, $Width / 2 - $hYellow_w / 1.5, $Height / 2 - $hYellow_w / 1.5)
    EndIf

    _GDIPlus_GraphicsDrawImageRect($hGraphics, $hBitmap, 0, 0, $Width, $Height)
    _WinAPI_UpdateLayeredWindowEx($hGUI, _GDIPlus_BitmapCreateHBITMAPFromBitmap($hBitmap), 255, 0)
WEnd

Func Pixel_Distance($x1, $y1, $x2, $y2) ;Pythagoras theorem
    Local $a, $b, $c
    If $x2 = $x1 And $y2 = $y1 Then Return 0
    $a = $y2 - $y1
    $b = $x2 - $x1
    $c = Sqrt($a * $a + $b * $b)
    Return $c
EndFunc   ;==>Pixel_Distance

Func _Exit()
    _GDIPlus_BitmapDispose($hBitmap)
    _GDIPlus_GraphicsDispose($hBackbuffer)
    _GDIPlus_GraphicsDispose($hGraphics)
    _GDIPlus_Shutdown()
    GUIDelete($hGUI)
    Exit
EndFunc

Func WM_NCHITTEST($hWnd, $iMsg, $iwParam, $ilParam)
    If ($hWnd = $hGui) And ($iMsg = $WM_NCHITTEST) Then Return $HTCAPTION
EndFunc ;==>WM_NCHITTEST

Thanks to Yasied for WinAPIEx.au3 and the images!

Br,

UEZ

Edited March 22, 2011 by UEZ

[mage123]

Thanks Yashied exactly what I was looking for and worked great

[bub]

I downloaded the images of the original code, however, the GUI is still not view.

I tried to remove $ WS_EX_LAYERED, the GUI is show, but not pictures.

The same thing happens with the GDI version of UEZ

It may be that I downloaded an older version of WinAPIEx?

Edited March 23, 2011 by bub

[UEZ]

I downloaded the images of the original code, however, the GUI is still not view.

I tried to remove $ WS_EX_LAYERED, the GUI is show, but not pictures.

The same thing happens with the GDI version of UEZ

It may be that I downloaded an older version of WinAPIEx?

For me it is still working with the latest WinAPIEx version - tested yesterday!

Probably the images cannot be loaded properly. Try @scriptdir & "\image.jpg"

Br,

UEZ
