I would like to present, the UDF for Debenu Quick PDF Library Getting Started: http://www.debenu.com/products/development/debenu-pdf-library/getting-started/getting-started-activex-edition/ Function Reference: http://www.debenu.com/docs/pdf_library_reference/FunctionGroups.php Useful information: http://www.quickpdf.org/forum/quickpdf-the-first-steps_topic1242.html http://www.quickpdflibrary.com/blog/2011/02/the-basics-getting-familiar-with-quick-pdf-library/ First time installing Debenu Quick PDF Library: You can download demo here: http://www.quickpdflibrary.com/downloads/quick_pdf_library_demo.exe Requirements: file "DebenuPDFLibraryLite1012.dll" or "DebenuPDFLibraryAX1014.dll" must be in @ScriptDir if you want to try you must download it from here: http://www.debenu.com/products/development/debenu-pdf-library/trial/ or http://www.debenu.com/products/development/debenu-pdf-library-lite/free/ after install you can find this dll in: "c:\Program Files (x86)\DebenuPDF Library\ActiveX\DebenuPDFLibraryAX1014.dll" or "c:\Program Files (x86)\DebenuPDF Library\Lite\DebenuPDFLibraryLite1012.dll" !!! you can change DLL to newer version using _QPDF_NewLibraryPath_Commercial() EDIT: actualy (19-06-2015) there is DebenuPDFLibraryAX1115.dll and DebenuPDFLibraryLite1115.dll to use the commercial version you need to use the _QPdf_SetLicenseKey()AutoIt 3.3.10.2++For UDF and examples download, and the current version information please go to download section: The following information are outdated 2014-05-14: 2014/05/14 v0.3 * removed examples from QuickPDF.au3 * added separate file with examples QuickPDF_Examples.au3 * added _QPDF_StartUp() * added _QPDF_NewLibraryPath_Commercial() * added _QPDF_NewLibraryPath_Lite() * __AddLeadingZeros changedt to __QPDF_AddLeadingZeros * CleanUp * _QPdf_ changed to _QPDF_ * Function Header - significantly supplemented * additional comments * new set of enum constants!!!!!!!!!!!!!!! SCRIPT BREAKING CHANGE !!!!!!!!!!!!!!! * Lite Function renaming to change your script you can use: ClipPut(StringRegExpReplace(ClipGet(),'(?i)(_QPDF)(_Lite)(_.*?)((|R)','$1$3$2$4')) * all functions which starts with "_QPDF__" now starts with "_QPDF_" it means one less "_" * _QPDF_FileSplitEachPage added new Parameters $sPDF_Password (as a second not third so $sDestinationDir is moved to third position * __QPDF_CreateObjectAndUnlock($oQP) change to _QPDF_CreateObjectAndUnlock($oQP) its mean is not internal any more =================================================== 2014-05-31: 2014/05/31 v0.4 QuickPDF.au3 * in __QPDF_UnlockKey() - Remarks changed * in _QPDF_StartUp() fixed: 'If Not FileExists($sDLLFile) Then' removed 'Not' * because of this process did not work on systems where the library was not registered using regsvr32.exe. * in _QPDF_StartUp() added: return values, but their functionality is not yet implemented and described (be expected to change within a week) * Added: new function: _QPDF_PrintPDFFile([$sPDF_FileFullPath = Default[, $sPDFPassword = ''[, $iDuplex = 1 ]]]) * Added: new function: _QPDF_MergeFiles($sFirstFileName, $sSecondFileName[, $sOutputFileName = Default]) QuickPDF_Examples.au3 * new example _QPDF_Example_MergeFiles() 2014/05/31 v0.5 QuickPDF.au3 * FIXED: in _QPDF_PrintPDFFile now printing all pages not only the first one 2014-07-02 NEW VERSION: 2014/07/02 v0.6 QuickPDF.au3 * added: #AutoIt3Wrapper_Au3Check_Parameters=-d -w 1 -w 2 -w 3 -w- 4 -w 5 -w 6 -w 7 and script CleanUp * added: new function _QPDF_ExtractTextFromStream() - you can use this function when you have data taken from Blob from SQL databese * added: new parameters _QPDF_NewLibraryPath_Commercial($sLibrary_NewFileFullPath, $sNewClassName, $sNewCLSID, $sNewIID) * #Region renaming - for better usage in SciTE Jump * in _QPDF_MergeFiles() -- litle change in $sOutputFileName = Default - add & '_temp.pdf' instead 'temp.pdf' * Changed: _QPDF_LastErrorCode -- Return Value containg description (string) and @error contain LastErrorCode * Changed: _QPDF_ExtractTextFromFile dafult $iExtractOptions = 7 for detail see here : http://www.quickpdf.org/forum/extractfilepagetext-options-0-and-8_topic2929.html * Removed: some MsgBox * Fixed: _QPDF_StartUp() - error checking for DllOpen QuickPDF_Examples.au3 * added: using new function _QPDF_NewLibraryPath_Commercial() for this you need DebenuPDFLibraryAX1015.dll _QPDF_NewLibraryPath_Commercial(@ScriptDir & 'DebenuPDFLibraryAX1015.dll', 'DebenuPDFLibraryAX1015.PDFLibrary', '{5D4196E9-0A7D-48DC-BD2C-7CD3FE771B38}', '{FA7270CF-D774-4A68-8368-2C3179895E0C}') QuickPDF_Calltip_Generator.au3 * NEW: use it to generate au3.QuickPDF.calltips.api OLD INFO: Before: 2014-05-05 OLD: Before: 2014-05-05 I'm working on UDF for http://www.quickpdf.org/ http://www.debenu.com/products/development/debenu-pdf-library/trial/ http://www.debenu.com/products/development/debenu-pdf-library/getting-started/getting-started-activex-edition/ For now I'm learning on the basis of examples of documentation: http://www.debenu.com/products/development/debenu-pdf-library/help/developer-guide/ http://www.debenu.com/docs/pdf_library_developer_guide/debenu_quick_pdf_library_10_developer_guide.pdf here is what I have: #include <MsgBoxConstants.au3> Global $__sClassName = "DebenuPDFLibraryAX1014.PDFLibrary" Global $__sLicenseKey = "....." ;'SET YOUR LICENSE KEY HERE... #CS C:\Windows\SysWOW64>regsvr32 "C:\Program Files\Debenu\PDF Library\ActiveX\DebenuPDFLibraryAX1014.dll" C:\Windows\SysWOW64>regsvr32 "c:\Program Files (x86)\Debenu\PDF Library\ActiveX\DebenuPDFLibrary64AX1014.dll" #CE _QPdf_Example_HelloWorld() _QPdf_Example_PrintDefault() Func __QPdf_UnlockKey($oQPdf, $sLicenseKey = Default) If $sLicenseKey = Default Then $sLicenseKey = $__sLicenseKey EndIf Local $Result = $oQPdf.UnlockKey($__sLicenseKey) If $Result <> 1 Then MsgBox($MB_SYSTEMMODAL, "info", "Invalid license key. Please set your license key by editing this file.") EndIf Return $Result EndFunc ;==>__QPdf_UnlockKey Func _QPdf_Example_HelloWorld() Local $sFileName = @ScriptDir & "\hello-world.pdf" Local $oQPdf = ObjCreate($__sClassName) If __QPdf_UnlockKey($oQPdf, $__sLicenseKey) = 1 Then ConsoleWrite("Library version: " & $oQPdf.LibraryVersion & @CRLF) ConsoleWrite("License Info: " & $oQPdf.LicenseInfo & @CRLF) $oQPdf.SetOrigin(1); $oQPdf.SetTextSize(20); $oQPdf.DrawText(100, 100, "Hello world from AutoIt") $oQPdf.SetTextSize(25); $oQPdf.DrawText(100, 200, "Hello world from AutoIt") $oQPdf.SetTextSize(30); $oQPdf.DrawText(100, 300, "Hello world from AutoIt") $oQPdf.SetTextSize(60); $oQPdf.SetTextColor(0, 0.5, 1); $oQPdf.DrawText(100, 400, "Hello world from AutoIt") If $oQPdf.SaveToFile($sFileName) = 1 Then MsgBox($MB_SYSTEMMODAL, "Info", "File " & $sFileName & " written successfully.") Else MsgBox($MB_SYSTEMMODAL, "Error", "File " & $sFileName & " could not be written.") EndIf EndIf EndFunc ;==>_QPdf_Example_HelloWorld Func _QPdf_Example_PrintDefault() ; based on Debenu Quick PDF Library 10 Developer Guide.pdf ; Standard PDF printing Local $sFileName = @ScriptDir & "\hello-world.pdf" Local $oQPdf = ObjCreate($__sClassName) If __QPdf_UnlockKey($oQPdf, $__sLicenseKey) = 1 Then ConsoleWrite("Library version: " & $oQPdf.LibraryVersion & @CRLF) ConsoleWrite("License Info: " & $oQPdf.LicenseInfo & @CRLF) $oQPdf.LoadFromFile($sFileName, ''); $iPrintOptions = $oQPdf.PrintOptions(0, 0, "Printing Sample 1") $oQPdf.PrintDocument($oQPdf.GetDefaultPrinterName(), 1, 1, $iPrintOptions); $iPrintOptions = $oQPdf.PrintOptions(0, 0, "Printing Sample 2") $oQPdf.PrintDocument($oQPdf.GetDefaultPrinterName(), 1, 1, $iPrintOptions); EndIf EndFunc ;==>_QPdf_Example_PrintDefault EDIT: First time installing Debenu Quick PDF Library: In order to download the current version of the UDF, download the attached file: QuickPDF.au3.Download.html QuickPDF.au3.Download.html

I need help. I have a project that outputs reports to PDF using @mLipok's lovely QuickPDF. The PDF is created with no problem and I am sure the problem is not there. However, I then have to open the PDF so the user can see it. I use (a) short file name and (b) object properties $oQP.SetPageLayout(2) $oQP.SetPageMode(3) ... $sFilename ; as created by UDF Local $sShortname = FileGetShortname( sFilename , 1 ) Run( @ComSpec & " /c start /max " & sShortname, "", @SW_HIDE ) ; force default PDF reader to open PDF maximized Then the RUN should open it with the default application. I have tested extensively on 32 bit Win7 and 64 bit Win10. Works. However, 64 bit Win8 and another Win7 laptop gives a problem. The problem is this: when (typically) Adobe Reader is ALREADY open, the PDF opens almost instantaneously. If the Reader is not open, it seems to stall. Never opens. The host on which the report will be opened is unknown to me and the PDF reader can not be hard coded. Right now, my only brutal, very un-stylish solution is to force the Reader open prior to the RUN command. Any ideas or advice on what causes this or how it could be remedied would be greatly appreciated. Anything, please. -Skysnake

I would ask for an indication of what is "The device context handle" in AutoIt. Below a handful of knowledge and examples, which, unfortunately, not quite speak to me (which is why I ask for help in clarifying their meaning). http://www.debenu.com/docs/pdf_library_reference/RenderPageToDC.php and C++ example: http://www.quickpdflibrary.com/faq/can-i-use-quick-pdf-as-a-viewer-in-my-c-application.php HWND m_hwnd = HWND(GDK_WINDOW_HWND(this->m_drawingArea.get_window()>gobj() )); HDC m_hdc = GetDC(m_hwnd); QP.RenderPageToDC(100, 1,(int)(HDC) m_hdc);
