New version available.

It's ok, its sorted! It was a mismatch between tree names and app names!

Here a first draft for creating barcodes using the Zint.dll (v2.15.09). Mor information about Zint can be found here: https://zint.org.uk Zint, libzint and Zint Barcode Studio are Copyright © 2022 Robin Stuart. All historical versions are distributed under the GNU General Public License version 3 or later. Version 2.5 (and later) is released under a dual license: the encoding library is released under the BSD license whereas the GUI, Zint Barcode Studio, is released under the GNU General Public License version 3 or later. The code became too long to post here! -> Download from my OneDrive: Zint Zint.au3 ;Coded by UEZ ;v0.60 build 2025-09-14 beta ;IMPORTANT: You are not allowed to sell this code or just parts of it in a commercial project or modify it and distribute it with a different name! ; Distributing copies of the program in compiled format (exe) must be free of any fee! #include-once #include "ZintDll.au3" Global $g__ZintDLL = @AutoItX64 ? (@ScriptDir & "\Zint64.dll") : (@ScriptDir & "\Zint.dll") #Region Constances ; === Barcode Symbologies === Global Const $BARCODE_CODE11 = 1 ; Code 11 Global Const $BARCODE_C25STANDARD = 2 ; 2 of 5 Standard (Matrix) Global Const $BARCODE_C25MATRIX = 2 ; Legacy Global Const $BARCODE_C25INTER = 3 ; 2 of 5 Interleaved Global Const $BARCODE_C25IATA = 4 ; 2 of 5 IATA Global Const $BARCODE_C25LOGIC = 6 ; 2 of 5 Data Logic Global Const $BARCODE_C25IND = 7 ; 2 of 5 Industrial Global Const $BARCODE_CODE39 = 8 ; Code 39 Global Const $BARCODE_EXCODE39 = 9 ; Extended Code 39 Global Const $BARCODE_EAN8 = 10 ; EAN-8 (GTIN-8) Global Const $BARCODE_EAN_2ADDON = 11 ; EAN/UPC 2-digit add-on Global Const $BARCODE_EAN_5ADDON = 12 ; EAN/UPC 5-digit add-on Global Const $BARCODE_EANX = 13 ; Legacy Global Const $BARCODE_EANX_CHK = 14 ; Legacy Global Const $BARCODE_EAN13 = 15 ; EAN-13 (GTIN-13) Global Const $BARCODE_GS1_128 = 16 ; GS1-128 Global Const $BARCODE_EAN128 = 16 ; Legacy Global Const $BARCODE_CODABAR = 18 ; Codabar Global Const $BARCODE_CODE128 = 20 ; Code 128 Global Const $BARCODE_DPLEIT = 21 ; Deutsche Post Leitcode Global Const $BARCODE_DPIDENT = 22 ; Deutsche Post Identcode Global Const $BARCODE_CODE16K = 23 ; Code 16k Global Const $BARCODE_CODE49 = 24 ; Code 49 Global Const $BARCODE_CODE93 = 25 ; Code 93 Global Const $BARCODE_FLAT = 28 ; Flattermarken Global Const $BARCODE_DBAR_OMN = 29 ; GS1 DataBar Omnidirectional Global Const $BARCODE_RSS14 = 29 ; Legacy Global Const $BARCODE_DBAR_LTD = 30 ; GS1 DataBar Limited Global Const $BARCODE_RSS_LTD = 30 ; Legacy Global Const $BARCODE_DBAR_EXP = 31 ; GS1 DataBar Expanded Global Const $BARCODE_RSS_EXP = 31 ; Legacy Global Const $BARCODE_TELEPEN = 32 ; Telepen Alpha Global Const $BARCODE_UPCA = 34 ; UPC-A Global Const $BARCODE_UPCA_CHK = 35 ; UPC-A including check digit Global Const $BARCODE_UPCE = 37 ; UPC-E Global Const $BARCODE_UPCE_CHK = 38 ; UPC-E including check digit Global Const $BARCODE_POSTNET = 40 ; USPS POSTNET Global Const $BARCODE_MSI_PLESSEY = 47 ; MSI Plessey Global Const $BARCODE_FIM = 49 ; Facing Identification Mark Global Const $BARCODE_LOGMARS = 50 ; LOGMARS Global Const $BARCODE_PHARMA = 51 ; Pharmacode One-Track Global Const $BARCODE_PZN = 52 ; Pharmazentralnummer Global Const $BARCODE_PHARMA_TWO = 53 ; Pharmacode Two-Track Global Const $BARCODE_CEPNET = 54 ; Brazilian CEPNet Postal Code Global Const $BARCODE_PDF417 = 55 ; PDF417 Global Const $BARCODE_PDF417COMP = 56 ; Compact PDF417 Global Const $BARCODE_PDF417TRUNC = 56 ; Legacy Global Const $BARCODE_MAXICODE = 57 ; MaxiCode Global Const $BARCODE_QRCODE = 58 ; QR Code Global Const $BARCODE_CODE128AB = 60 ; Code 128 (Suppress Code Set C) Global Const $BARCODE_CODE128B = 60 ; Legacy Global Const $BARCODE_AUSPOST = 63 ; Australia Post Standard Customer Global Const $BARCODE_AUSREPLY = 66 ; Australia Post Reply Paid Global Const $BARCODE_AUSROUTE = 67 ; Australia Post Routing Global Const $BARCODE_AUSREDIRECT = 68 ; Australia Post Redirection Global Const $BARCODE_ISBNX = 69 ; ISBN Global Const $BARCODE_RM4SCC = 70 ; Royal Mail 4-State Global Const $BARCODE_DATAMATRIX = 71 ; Data Matrix (ECC200) Global Const $BARCODE_EAN14 = 72 ; EAN-14 Global Const $BARCODE_VIN = 73 ; Vehicle Identification Number Global Const $BARCODE_CODABLOCKF = 74 ; Codablock-F Global Const $BARCODE_NVE18 = 75 ; NVE-18 (SSCC-18) Global Const $BARCODE_JAPANPOST = 76 ; Japanese Postal Code Global Const $BARCODE_KOREAPOST = 77 ; Korea Post Global Const $BARCODE_DBAR_STK = 79 ; GS1 DataBar Stacked Global Const $BARCODE_RSS14STACK = 79 ; Legacy Global Const $BARCODE_DBAR_OMNSTK = 80 ; GS1 DataBar Stacked Omnidirectional Global Const $BARCODE_RSS14STACK_OMNI = 80 ; Legacy Global Const $BARCODE_DBAR_EXPSTK = 81 ; GS1 DataBar Expanded Stacked Global Const $BARCODE_RSS_EXPSTACK = 81 ; Legacy Global Const $BARCODE_PLANET = 82 ; USPS PLANET Global Const $BARCODE_MICROPDF417 = 84 ; MicroPDF417 Global Const $BARCODE_USPS_IMAIL = 85 ; USPS Intelligent Mail Global Const $BARCODE_ONECODE = 85 ; Legacy Global Const $BARCODE_PLESSEY = 86 ; UK Plessey Global Const $BARCODE_TELEPEN_NUM = 87 ; Telepen Numeric Global Const $BARCODE_ITF14 = 89 ; ITF-14 Global Const $BARCODE_KIX = 90 ; Dutch Post KIX Global Const $BARCODE_AZTEC = 92 ; Aztec Global Const $BARCODE_DAFT = 93 ; DAFT Global Const $BARCODE_DPD = 96 ; DPD Global Const $BARCODE_MICROQR = 97 ; Micro QR Global Const $BARCODE_HIBC_128 = 98 ; HIBC Code 128 Global Const $BARCODE_HIBC_39 = 99 ; HIBC Code 39 Global Const $BARCODE_HIBC_DM = 102 ; HIBC Data Matrix Global Const $BARCODE_HIBC_QR = 104 ; HIBC QR Global Const $BARCODE_HIBC_PDF = 106 ; HIBC PDF417 Global Const $BARCODE_HIBC_MICPDF = 108 ; HIBC MicroPDF417 Global Const $BARCODE_HIBC_BLOCKF = 110 ; HIBC Codablock-F Global Const $BARCODE_HIBC_AZTEC = 112 ; HIBC Aztec Global Const $BARCODE_DOTCODE = 115 ; DotCode Global Const $BARCODE_HANXIN = 116 ; Han Xin Global Const $BARCODE_MAILMARK_2D = 119 ; Royal Mail 2D Mailmark Global Const $BARCODE_UPU_S10 = 120 ; UPU S10 Global Const $BARCODE_MAILMARK_4S = 121 ; Royal Mail 4-State Mailmark Global Const $BARCODE_MAILMARK = 121 ; Legacy Global Const $BARCODE_AZRUNE = 128 ; Aztec Runes Global Const $BARCODE_CODE32 = 129 ; Code 32 Global Const $BARCODE_EANX_CC = 130 ; Legacy Global Const $BARCODE_GS1_128_CC = 131 ; GS1-128 Composite Global Const $BARCODE_EAN128_CC = 131 ; Legacy Global Const $BARCODE_DBAR_OMN_CC = 132 ; DataBar Omnidirectional Composite Global Const $BARCODE_RSS14_CC = 132 ; Legacy Global Const $BARCODE_DBAR_LTD_CC = 133 ; DataBar Limited Composite Global Const $BARCODE_RSS_LTD_CC = 133 ; Legacy Global Const $BARCODE_DBAR_EXP_CC = 134 ; DataBar Expanded Composite Global Const $BARCODE_RSS_EXP_CC = 134 ; Legacy Global Const $BARCODE_UPCA_CC = 135 ; UPC-A Composite Global Const $BARCODE_UPCE_CC = 136 ; UPC-E Composite Global Const $BARCODE_DBAR_STK_CC = 137 ; DataBar Stacked Composite Global Const $BARCODE_RSS14STACK_CC = 137 ; Legacy Global Const $BARCODE_DBAR_OMNSTK_CC = 138 ; DataBar Stacked Omnidirectional Composite Global Const $BARCODE_RSS14_OMNI_CC = 138 ; Legacy Global Const $BARCODE_DBAR_EXPSTK_CC = 139 ; DataBar Expanded Stacked Composite Global Const $BARCODE_RSS_EXPSTACK_CC = 139 ; Legacy Global Const $BARCODE_CHANNEL = 140 ; Channel Code Global Const $BARCODE_CODEONE = 141 ; Code One Global Const $BARCODE_GRIDMATRIX = 142 ; Grid Matrix Global Const $BARCODE_UPNQR = 143 ; UPNQR Global Const $BARCODE_ULTRA = 144 ; Ultracode Global Const $BARCODE_RMQR = 145 ; Rectangular Micro QR Global Const $BARCODE_BC412 = 146 ; IBM BC412 Global Const $BARCODE_DXFILMEDGE = 147 ; DX Film Edge Global Const $BARCODE_EAN8_CC = 148 ; EAN-8 Composite Global Const $BARCODE_EAN13_CC = 149 ; EAN-13 Composite Global Const $BARCODE_LAST = 149 ; Max marker ; === Output options === Global Const $BARCODE_BIND_TOP = 0x00001 ; Bind top Global Const $BARCODE_BIND = 0x00002 ; Bind bottom Global Const $BARCODE_BOX = 0x00004 ; Box around symbol Global Const $BARCODE_STDOUT = 0x00008 ; Output to stdout Global Const $READER_INIT = 0x00010 ; Reader Initialisation Global Const $SMALL_TEXT = 0x00020 ; Small human readable text Global Const $BOLD_TEXT = 0x00040 ; Bold human readable text Global Const $CMYK_COLOUR = 0x00080 ; Use CMYK in EPS Global Const $BARCODE_DOTTY_MODE = 0x00100 ; Dotty mode Global Const $GS1_GS_SEPARATOR = 0x00200 ; Use GS as separator Global Const $OUT_BUFFER_INTERMEDIATE = 0x00400 ; Return intermediate data Global Const $BARCODE_QUIET_ZONES = 0x00800 ; Force quiet zones Global Const $BARCODE_NO_QUIET_ZONES = 0x01000 ; Suppress quiet zones Global Const $COMPLIANT_HEIGHT = 0x02000 ; Compliant height Global Const $EANUPC_GUARD_WHITESPACE = 0x04000 ; Guard whitespace Global Const $EMBED_VECTOR_FONT = 0x08000 ; Embed vector font Global Const $BARCODE_MEMORY_FILE = 0x10000 ; Output to memory Global Const $BARCODE_RAW_TEXT = 0x20000 ; Output raw text ; === Input modes === Global Const $DATA_MODE = 0 ; Binary input Global Const $UNICODE_MODE = 1 ; Unicode input Global Const $GS1_MODE = 2 ; GS1 input Global Const $ESCAPE_MODE = 0x0008 ; Escape sequences Global Const $GS1PARENS_MODE = 0x0010 ; GS1 parentheses Global Const $GS1NOCHECK_MODE = 0x0020 ; Skip GS1 checks Global Const $HEIGHTPERROW_MODE = 0x0040 ; Height per row Global Const $FAST_MODE = 0x0080 ; Fast mode Global Const $EXTRA_ESCAPE_MODE = 0x0100 ; Extra escape Global Const $GS1SYNTAXENGINE_MODE = 0x0200 ; GS1 syntax engine ; === Data Matrix options === Global Const $DM_SQUARE = 100 ; Square only Global Const $DM_DMRE = 101 ; DMRE only Global Const $DM_ISO_144 = 128 ; ISO 144 compliance ; === QR/Han Xin/Grid Matrix options === Global Const $ZINT_FULL_MULTIBYTE = 200 ; Full multibyte ; === Ultracode options === Global Const $ULTRA_COMPRESSION = 128 ; Compression mode ; === Warnings & Errors === Global Const $ZINT_WARN_HRT_TRUNCATED = 1 ; HRT truncated Global Const $ZINT_WARN_INVALID_OPTION = 2 ; Invalid option Global Const $ZINT_WARN_USES_ECI = 3 ; Uses ECI Global Const $ZINT_WARN_NONCOMPLIANT = 4 ; Noncompliant symbol Global Const $ZINT_ERROR = 5 ; General error Global Const $ZINT_ERROR_TOO_LONG = 5 ; Data too long Global Const $ZINT_ERROR_INVALID_DATA = 6 ; Invalid data Global Const $ZINT_ERROR_INVALID_CHECK = 7 ; Invalid check digit Global Const $ZINT_ERROR_INVALID_OPTION = 8 ; Invalid option Global Const $ZINT_ERROR_ENCODING_PROBLEM = 9 ; Encoding problem Global Const $ZINT_ERROR_FILE_ACCESS = 10 ; File access error Global Const $ZINT_ERROR_MEMORY = 11 ; Memory error Global Const $ZINT_ERROR_FILE_WRITE = 12 ; File write error Global Const $ZINT_ERROR_USES_ECI = 13 ; Uses ECI Global Const $ZINT_ERROR_NONCOMPLIANT = 14 ; Noncompliant Global Const $ZINT_ERROR_HRT_TRUNCATED = 15 ; HRT truncated ; === Warning levels === Global Const $WARN_DEFAULT = 0 ; Default warnings Global Const $WARN_FAIL_ALL = 2 ; Treat all warnings as errors ; === Capabilities === Global Const $ZINT_CAP_HRT = 0x0001 ; Has HRT Global Const $ZINT_CAP_STACKABLE = 0x0002 ; Stackable Global Const $ZINT_CAP_EANUPC = 0x0004 ; EAN/UPC Global Const $ZINT_CAP_EXTENDABLE = 0x0004 ; Extendable (legacy) Global Const $ZINT_CAP_COMPOSITE = 0x0008 ; Composite Global Const $ZINT_CAP_ECI = 0x0010 ; ECI capable Global Const $ZINT_CAP_GS1 = 0x0020 ; GS1 capable Global Const $ZINT_CAP_DOTTY = 0x0040 ; Dotty capable Global Const $ZINT_CAP_QUIET_ZONES = 0x0080 ; Quiet zones Global Const $ZINT_CAP_FIXED_RATIO = 0x0100 ; Fixed ratio Global Const $ZINT_CAP_READER_INIT = 0x0200 ; Reader Init Global Const $ZINT_CAP_FULL_MULTIBYTE = 0x0400 ; Full multibyte Global Const $ZINT_CAP_MASK = 0x0800 ; Masking Global Const $ZINT_CAP_STRUCTAPP = 0x1000 ; Structured Append Global Const $ZINT_CAP_COMPLIANT_HEIGHT = 0x2000 ; Compliant height Global Const $ZINT_CAP_BINDABLE = 0x4000 ; Bindable ; === Limits === Global Const $ZINT_MAX_DATA_LEN = 17400 ; Max data length Global Const $ZINT_MAX_SEG_COUNT = 256 ; Max segment count #EndRegion #Region Structs ; Vector elements Global Const $tag_zint_vector_rect = "struct;" & _ "float x;" & _ ; Top left "float y;" & _ "float height;" & _ "float width;" & _ "long colour;" & _ ; -1 foreground, 1-8 = Cyan, Blue, Magenta, Red, Yellow, Green, Black, White "ptr next;" & _ ; Pointer to next rectangle "endstruct" Global Const $tag_zint_vector_hexagon = "struct;" & _ "float x;" & _ ; Centre x "float y;" & _ ; Centre y "float diameter;" & _ ; Short diameter (inscribed circle) "long rotation;" & _ ; 0, 90, 180, 270 (0 = apex at top) "ptr next;" & _ ; Pointer to next hexagon "endstruct" Global Const $tag_zint_vector_string = "struct;" & _ "float x;" & _ ; Relative to halign "float y;" & _ ; Relative to baseline "float fsize;" & _ ; Font size "float width;" & _ ; Rendered width estimate "long length;" & _ ; Number of characters (bytes) "long rotation;" & _ ; 0, 90, 180, 270 "long halign;" & _ ; 0 = centre, 1 = left, 2 = right "ptr text;" & _ ; UTF-8, NUL-terminated "ptr next;" & _ ; Pointer to next string "endstruct" Global Const $tag_zint_vector_circle = "struct;" & _ "float x;" & _ ; Centre x "float y;" & _ ; Centre y "float diameter;" & _ ; Circle diameter (excludes width) "float width;" & _ ; Perimeter width, 0 = fill "long colour;" & _ ; 0 = foreground colour, else background "ptr next;" & _ ; Pointer to next circle "endstruct" Global Const $tag_zint_vector = "struct;" & _ "float width;" & _ ; Overall barcode width "float height;" & _ ; Overall barcode height "ptr rectangles;" & _ ; Pointer to first rectangle "ptr hexagons;" & _ ; Pointer to first hexagon "ptr strings;" & _ ; Pointer to first string "ptr circles;" & _ ; Pointer to first circle "endstruct" ; Structured Append info Global Const $tag_zint_structapp = "long index;" & _ ; Position in sequence (1-based) "long count;" & _ ; Number of symbols in sequence "char id[32];" ; Optional ID, ASCII, NUL-terminated ; Segment info Global Const $tag_zint_seg = "struct;" & _ "ptr source;" & _ ; Data pointer "long length;" & _ ; Data length (0 = NUL-terminated) "long eci;" & _ ; Extended Channel Interpretation "endstruct" ; Main symbol structure Global Const $tag_zint_symbol = "struct;" & _ "long symbology;" & _ ; Symbol type "float height;" & _ ; Barcode height "float scale;" & _ ; Scale factor "long whitespace_width;" & _ ; Horizontal whitespace "long whitespace_height;" & _ ; Vertical whitespace "long border_width;" & _ ; Border width "long output_options;" & _ ; Output options "char fgcolour[16];" & _ ; Foreground colour string "char bgcolour[16];" & _ ; Background colour string "ptr fgcolor;" & _ ; Pointer to fgcolour "ptr bgcolor;" & _ ; Pointer to bgcolour "char outfile[256];" & _ ; Output filename "char primary[128];" & _ ; Primary message data "long option_1;" & _ ; Symbol-specific option "long option_2;" & _ "long option_3;" & _ "long show_hrt;" & _ ; Show (1) / hide (0) human readable text "long input_mode;" & _ ; Input encoding "long eci;" & _ ; Extended Channel Interpretation "float dpmm;" & _ ; Resolution in dots/mm "float dot_size;" & _ ; Dot size (dotty mode) "float text_gap;" & _ ; Gap between barcode and text "float guard_descent;" & _ ; EAN/UPC guard bar descent $tag_zint_structapp & _ ; Structured append info "long warn_level;" & _ ; Warning behaviour "long debug;" & _ ; Debug flags "byte text[256];" & _ ; Human-readable text (output) "long text_length;" & _ ; Length of text (output) "long rows;" & _ ; Number of rows (output) "long width;" & _ ; Symbol width (output) "byte encoded_data[28800];" & _ ; Encoded data (flattened 200x144) "float row_height[200];" & _ ; Row heights "char errtxt[160];" & _ ; Error text (output) "ptr bitmap;" & _ ; Bitmap pointer (output) "long bitmap_width;" & _ ; Bitmap width "long bitmap_height;" & _ ; Bitmap height "ptr alphamap;" & _ ; Alpha channel pointer "ptr vector;" & _ ; Vector header pointer "ptr memfile;" & _ ; In-memory file buffer "long memfile_size;" & _ ; Buffer length "ptr raw_segs;" & _ ; Raw segments pointer "long raw_seg_count;" & _ ; Number of raw segs "endstruct" #EndRegion #Region Functions ; Create and initialize a symbol structure Func ZBarcode_Create() If Not FileExists($g__ZintDLL) Then If @AutoItX64 Then _zint64dll(True) Else _zintdll(True) EndIf EndIf Local $hPtr = DllCall($g__ZintDLL, "ptr:cdecl", "ZBarcode_Create")[0] If $hPtr = 0 Then Return SetError(2, 0, 0) Return $hPtr EndFunc ; Free any output buffers that may have been created and initialize output fields Func ZBarcode_Clear($pSymbol) If IsPtr($pSymbol) And $pSymbol <> 0 Then DllCall($g__ZintDLL, "none:cdecl", "ZBarcode_Clear", "ptr", $pSymbol) Return 1 EndIf Return SetError(1, 0, 0) EndFunc ; Free any output buffers that may have been created and reset all fields to defaults Func ZBarcode_Reset($pSymbol) If IsPtr($pSymbol) And $pSymbol <> 0 Then DllCall($g__ZintDLL, "none:cdecl", "ZBarcode_Reset", "ptr", $pSymbol) Return 1 EndIf Return SetError(1, 0, 0) EndFunc ; Free a symbol structure, including any output buffers Func ZBarcode_Delete($pSymbol) If IsPtr($pSymbol) And $pSymbol <> 0 Then DllCall($g__ZintDLL, "none:cdecl", "ZBarcode_Delete", "ptr", $pSymbol) Return 1 EndIf Return SetError(1, 0, 0) EndFunc ; =================================================================== ; Encoding ; =================================================================== ; Encode a barcode. If length is 0 or negative, source must be NUL-terminated Func ZBarcode_Encode($pSymbol, $sInput) Local $iLength = StringLen($sInput) Local $tInput = DllStructCreate("struct;ubyte text[" & $iLength + 1 & "];endstruct") $tInput.text = $sInput Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode", "ptr", $pSymbol, "struct*", $tInput, "long", $iLength + 1)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc ; Encode a barcode with multiple ECI segments Func ZBarcode_Encode_Segs($pSymbol, $pSegs, $iSegCount) Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode_Segs", "ptr", $pSymbol, "ptr", $pSegs, "long", $iSegCount)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc ; Encode a barcode using input data from file Func ZBarcode_Encode_File($pSymbol, $sFilename) Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode_File", "ptr", $pSymbol, "str", $sFilename)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc ; =================================================================== ; Output to file ; =================================================================== ; Output a previously encoded symbol to file Func ZBarcode_Print($pSymbol, $iAngle = 0) Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Print", "ptr", $pSymbol, "long", $iAngle)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc ; Encode and output a symbol to file Func ZBarcode_Encode_and_Print($pSymbol, $sInput, $iRotate = 0) Local $iLength = StringLen($sInput) Local $tInput = DllStructCreate("struct;ubyte text[" & $iLength + 1 & "];endstruct") $tInput.text = $sInput Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode_and_Print", "ptr", $pSymbol, "struct*", $tInput, "long", $iLength + 1, "long", $iRotate)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc ; Encode a symbol with multiple ECI segments and output to file Func ZBarcode_Encode_Segs_and_Print($pSymbol, $pSegs, $iSegCount, $iRotate = 0) Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode_Segs_and_Print", "ptr", $pSymbol, "ptr", $pSegs, "long", $iSegCount, "long", $iRotate)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc ; Encode a symbol using input data from file and output to file Func ZBarcode_Encode_File_and_Print($pSymbol, $sFilename, $iRotate = 0) Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode_File_and_Print", "ptr", $pSymbol, "str", $sFilename, "long", $iRotate)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc ; =================================================================== ; Output to memory (raster/vector) ; =================================================================== Func ZBarcode_Buffer($pSymbol, $iAngle = 0) Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Buffer", "ptr", $pSymbol, "long", $iAngle)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc Func ZBarcode_Encode_and_Buffer($pSymbol, $sInput, $iRotate = 0) Local $iLength = StringLen($sInput) Local $tInput = DllStructCreate("struct;ubyte text[" & $iLength + 1 & "];endstruct") $tInput.text = $sInput Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode_and_Buffer", "ptr", $pSymbol, "struct*", $tInput, "long", $iLength + 1, "long", $iRotate)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc Func ZBarcode_Encode_Segs_and_Buffer($pSymbol, $pSegs, $iSegCount, $iRotate = 0) Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode_Segs_and_Buffer", "ptr", $pSymbol, "ptr", $pSegs, "long", $iSegCount, "long", $iRotate)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc Func ZBarcode_Encode_File_and_Buffer($pSymbol, $sFilename, $iRotate = 0) Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode_File_and_Buffer", "ptr", $pSymbol, "str", $sFilename, "long", $iRotate)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc Func ZBarcode_Buffer_Vector($pSymbol, $iAngle = 0) Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Buffer_Vector", "ptr", $pSymbol, "long", $iAngle)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc Func ZBarcode_Encode_and_Buffer_Vector($pSymbol, $sInput, $iRotate = 0) Local $iLength = StringLen($sInput) Local $tInput = DllStructCreate("struct;ubyte text[" & $iLength + 1 & "];endstruct") $tInput.text = $sInput Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode_and_Buffer_Vector", "ptr", $pSymbol, "struct*", $tInput, "long", $iLength + 1, "long", $iRotate)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc Func ZBarcode_Encode_Segs_and_Buffer_Vector($pSymbol, $pSegs, $iSegCount, $iRotate = 0) Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode_Segs_and_Buffer_Vector", "ptr", $pSymbol, "ptr", $pSegs, "long", $iSegCount, "long", $iRotate)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc Func ZBarcode_Encode_File_and_Buffer_Vector($pSymbol, $sFilename, $iRotate = 0) Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Encode_File_and_Buffer_Vector", "ptr", $pSymbol, "str", $sFilename, "long", $iRotate)[0] If $iResult Then Return SetError($iResult, 0, 0) Return 1 EndFunc ; =================================================================== ; Info & Validation ; =================================================================== ; Is symbol_id a recognized symbology? Func ZBarcode_ValidID($iSymbolID) Return DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_ValidID", "long", $iSymbolID)[0] EndFunc ; Copy BARCODE_XXX name of symbol_id into name buffer Func ZBarcode_BarcodeName($iSymbolID) Local $tName = DllStructCreate("char[32]") Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_BarcodeName", "long", $iSymbolID, "struct*", $tName)[0] If $iResult Then Return SetError($iResult, 0, "") Return DllStructGetData($tName, 1) EndFunc ; Return the capability flags for symbology symbol_id that match cap_flag Func ZBarcode_Cap($iSymbolID, $iCapFlag) Return DllCall($g__ZintDLL, "uint:cdecl", "ZBarcode_Cap", "long", $iSymbolID, "uint", $iCapFlag)[0] EndFunc ; =================================================================== ; X-dimension & Scaling ; =================================================================== Func ZBarcode_Default_Xdim($iSymbolID) Return DllCall($g__ZintDLL, "float:cdecl", "ZBarcode_Default_Xdim", "long", $iSymbolID)[0] EndFunc Func ZBarcode_Scale_From_XdimDp($iSymbolID, $fXDimMM, $fDpmm, $sFiletype = "") Return DllCall($g__ZintDLL, "float:cdecl", "ZBarcode_Scale_From_XdimDp", _ "long", $iSymbolID, "float", $fXDimMM, "float", $fDpmm, "str", $sFiletype)[0] EndFunc Func ZBarcode_XdimDp_From_Scale($iSymbolID, $fScale, $fXDimOrDpmm, $sFiletype = "") Return DllCall($g__ZintDLL, "float:cdecl", "ZBarcode_XdimDp_From_Scale", _ "long", $iSymbolID, "float", $fScale, "float", $fXDimOrDpmm, "str", $sFiletype)[0] EndFunc ; =================================================================== ; UTF-8 & ECI helpers ; =================================================================== Func ZBarcode_UTF8_To_ECI($iEci, $sSource, ByRef $sDest) Local $iLength = StringLen($sSource) Local $tSrc = DllStructCreate("struct;ubyte text[" & $iLength + 1 & "];endstruct") $tSrc.text = $sSource Local $tDest = DllStructCreate("ubyte[1024]") ; allocate buffer Local $pDestLen = DllStructCreate("int") Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_UTF8_To_ECI", "long", $iEci, "struct*", $tSrc, "long", $iLength + 1, "struct*", $tDest, "struct*", $pDestLen)[0] If $iResult Then Return SetError($iResult, 0, "") $sDest = BinaryToString(DllStructGetData($tDest, 1)) Return 1 EndFunc Func ZBarcode_Dest_Len_ECI($iEci, $sSource) Local $iLength = StringLen($sSource) Local $tSrc = DllStructCreate("struct;ubyte text[" & $iLength + 1 & "];endstruct") $tSrc.text = $sSource Local $pDestLen = DllStructCreate("int") Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Dest_Len_ECI", "long", $iEci, "struct*", $tSrc, "long", $iLength + 1, "struct*", $pDestLen)[0] If $iResult Then Return SetError($iResult, 0, 0) Return DllStructGetData($pDestLen, 1) EndFunc ; =================================================================== ; Build info ; =================================================================== Func ZBarcode_NoPng() Return DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_NoPng")[0] EndFunc Func ZBarcode_HaveGS1SyntaxEngine() Return DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_HaveGS1SyntaxEngine")[0] EndFunc ; Return the version of Zint linked to Func ZBarcode_Version() Local $iResult = DllCall($g__ZintDLL, "long:cdecl", "ZBarcode_Version")[0] Local $a = StringRegExp((Mod(StringLen($iResult), 2) ? "0" : "") & $iResult, ".{2}", 3) If Not IsArray($a) Then Return SetError(1, 0, 0) Return StringFormat("%01i.%02i.%02i", $a[0], $a[1], $a[2]) EndFunc #EndRegion Example1.au3 #AutoIt3Wrapper_UseX64=y #include <GDIPlus.au3> #include "Zint.au3" Global Const $sTestFile = "out.png" ;default output name If FileExists($sTestFile) Then FileDelete($sTestFile) Global $pZB = ZBarcode_Create() If @error Then Exit MsgBox(16, "ERROR", "An error occured!" & @CRLF & "Error code = " & @error, 10) ConsoleWrite("Zint DLL version: " & ZBarcode_Version() & @CRLF) ConsoleWrite("PNG support: " & (ZBarcode_NoPng() ? "No" : "Yes") & @CRLF) Global $t_zint_symbol = DllStructCreate($tag_zint_symbol, $pZB) If @error Then MsgBox(16, "ERROR", "An error occured!" & @CRLF & "Error code = " & @error, 10) ZBarcode_Delete($pZB) Exit EndIf With $t_zint_symbol .symbology = $BARCODE_CODE128 .scale = 1 .option_1 = -1 .show_hrt = 1 .output_options = $SMALL_TEXT .outfile = $sTestFile EndWith ZBarcode_Encode_and_Print($pZB, "12340984576") Global $iError = @error ZBarcode_Delete($pZB) If FileExists($sTestFile) Then ShellExecute($sTestFile) Else MsgBox(16, "Error", "Code was not create. Error: " & $iError, 5) EndIf Example2.au3 #AutoIt3Wrapper_UseX64=n #include <GDIPlus.au3> #include <GUIConstantsEx.au3> #include "Zint.au3" Global Const $sTestFile = @ScriptDir & "\Barcode.png" Global $pZB = ZBarcode_Create() If @error Then Exit MsgBox(16, "ERROR", "An error occured!" & @CRLF & "Error code = " & @error, 10) Global $t_zint_symbol = DllStructCreate($tag_zint_symbol, $pZB) $t_zint_symbol.symbology = $BARCODE_QRCODE $t_zint_symbol.scale = 10 ZBarcode_Encode_and_Buffer($pZB, "Hello QR World ;-)") _GDIPlus_Startup() Global $stride = BitAND(($t_zint_symbol.bitmap_width * 3) + 3, BitNOT(3)) Global $iMemSize = $stride * $t_zint_symbol.bitmap_height Global $tPixel = DllStructCreate("ubyte rgb[" & $iMemSize & "];") Global $hBitmap = _GDIPlus_BitmapCreateFromScan0($t_zint_symbol.bitmap_width, $t_zint_symbol.bitmap_height, $GDIP_PXF24RGB, $stride, $tPixel) DllCall("msvcrt.dll", "ptr:cdecl", "memcpy", "struct*", $tPixel, "ptr", $t_zint_symbol.bitmap, "uint", $iMemSize) Global Const $hGUI = GUICreate("Test QR Code", $t_zint_symbol.bitmap_width, $t_zint_symbol.bitmap_height) GUISetState(@SW_SHOW) Global Const $hGfx = _GDIPlus_GraphicsCreateFromHWND($hGUI) _GDIPlus_GraphicsDrawImageRect($hGfx, $hBitmap, 0, 0, $t_zint_symbol.bitmap_width, $t_zint_symbol.bitmap_height) _GDIPlus_GraphicsDispose($hGfx) _GDIPlus_ImageDispose($hBitmap) _GDIPlus_Shutdown() ZBarcode_Delete($pZB) Do Until GUIGetMsg() = $GUI_EVENT_CLOSE Example3.au3 #AutoIt3Wrapper_UseX64=n #include <GDIPlus.au3> #include <GUIConstantsEx.au3> #include "Zint.au3" Global $pZB = ZBarcode_Create() If @error Then Exit MsgBox(16, "ERROR", "An error occured!" & @CRLF & "Error code = " & @error, 10) Global $t_zint_symbol = DllStructCreate($tag_zint_symbol, $pZB), $sText = "12340984576 ;-)" With $t_zint_symbol .symbology = $BARCODE_CODE128 .scale = 1 EndWith If Not ZBarcode_Encode_and_Buffer_Vector($pZB, $sText) Then Exit MsgBox(16, "ERROR", "Unable to encode!" & @CRLF & "Error code = " & @error, 10) Global $tVector = DllStructCreate($tag_zint_vector, $t_zint_symbol.vector) Global $tVector_Rect = DllStructCreate($tag_zint_vector_rect, $tVector.rectangles) ConsoleWrite($tVector.width & " x " & $tVector.height & @CRLF) _GDIPlus_Startup() Global $hBitmap = _GDIPlus_BitmapCreateFromScan0($tVector.width, $tVector.height, $GDIP_PXF24RGB), $hCanvas = _GDIPlus_ImageGetGraphicsContext($hBitmap), $hBrush = _GDIPlus_BrushCreateSolid() _GDIPlus_GraphicsClear($hCanvas, 0xFFFFFFFF) While $tVector_Rect.next _GDIPlus_BrushSetSolidColor($hBrush, BitAND($tVector_Rect.colour, 0xFF000000)) _GDIPlus_GraphicsFillRect($hCanvas, $tVector_Rect.x, $tVector_Rect.y, $tVector_Rect.width, $tVector_Rect.height, $hBrush) $tVector_Rect = DllStructCreate($tag_zint_vector_rect, $tVector_Rect.next) WEnd Global $tVector_String = DllStructCreate($tag_zint_vector_string, $tVector.strings) _GDIPlus_GraphicsDrawString($hCanvas, $sText, ($tVector_String.width - $tVector_String.length * $tVector_String.fsize * 0.55) / 2, $tVector.height - $tVector_String.fsize * 1.33333, "Arial", $tVector_String.fsize * 0.75, Default, 0xFF000000) Global Const $hGUI = GUICreate("Test Bar Code 128", $tVector.width, $tVector.height) GUISetState(@SW_SHOW) Global Const $hGfx = _GDIPlus_GraphicsCreateFromHWND($hGUI) _GDIPlus_GraphicsDrawImageRect($hGfx, $hBitmap, 0, 0, $tVector.width, $tVector.height) _GDIPlus_GraphicsDispose($hCanvas) _GDIPlus_GraphicsDispose($hGfx) _GDIPlus_ImageDispose($hBitmap) _GDIPlus_BrushDispose($hBrush) _GDIPlus_Shutdown() ZBarcode_Delete($pZB) Do Until GUIGetMsg() = $GUI_EVENT_CLOSE Example4.au3 #AutoIt3Wrapper_UseX64=y #include "Zint.au3" ; =================================================================== ; Zint AutoIt Demo Test ; =================================================================== ; ------------------------------------------------------------------- ; Step 1: Create a symbol ; ------------------------------------------------------------------- ConsoleWrite("Step 1: Create a symbol" & @CRLF) Global $pSymbol = ZBarcode_Create() If @error Then MsgBox(16, "Error", "Failed to create symbol") Exit EndIf ConsoleWrite("Symbol created: " & $pSymbol & @CRLF) ConsoleWrite(@CRLF) ; ------------------------------------------------------------------- ; Step 2: Encode a simple string ; ------------------------------------------------------------------- ConsoleWrite("Step 2: Encode a simple string" & @CRLF) Global $sData = "HELLO123" If ZBarcode_Encode($pSymbol, $sData) Then ConsoleWrite("Encoding succeeded" & @CRLF) Else ConsoleWrite("Encoding failed, error: " & @error & @CRLF) EndIf ConsoleWrite(@CRLF) ; ------------------------------------------------------------------- ; Step 3: Output to raster buffer ; ------------------------------------------------------------------- ConsoleWrite("Step 3: Output to raster buffer" & @CRLF) If ZBarcode_Buffer($pSymbol) Then ConsoleWrite("Raster buffer generated successfully" & @CRLF) Else ConsoleWrite("Raster buffer generation failed, error: " & @error & @CRLF) EndIf ConsoleWrite(@CRLF) ; ------------------------------------------------------------------- ; Step 4: Output to vector buffer ; ------------------------------------------------------------------- ConsoleWrite("Step 4: Output to vector buffer" & @CRLF) If ZBarcode_Buffer_Vector($pSymbol) Then ConsoleWrite("Vector buffer generated successfully" & @CRLF) Else ConsoleWrite("Vector buffer generation failed, error: " & @error & @CRLF) EndIf ConsoleWrite(@CRLF) ; ------------------------------------------------------------------- ; Step 5: Print to file (just test call, file may not exist) ; ------------------------------------------------------------------- ConsoleWrite("Step 5: Print to file" & @CRLF) Global $t_zint_symbol = DllStructCreate($tag_zint_symbol, $pSymbol) $t_zint_symbol.symbology = $BARCODE_CODE128 $t_zint_symbol.input_mode = $DATA_MODE $t_zint_symbol.height = 50 $t_zint_symbol.scale = 1 $t_zint_symbol.option_1 = 0 $t_zint_symbol.option_2 = 0 $t_zint_symbol.option_3 = 0 $t_zint_symbol.show_hrt = 1 If ZBarcode_Print(DllStructGetPtr($t_zint_symbol)) Then ConsoleWrite("Print function call succeeded" & @CRLF) Else ConsoleWrite("Print failed, error: " & @error & @CRLF) EndIf ConsoleWrite(@CRLF) ; ------------------------------------------------------------------- ; Step 6: Get barcode info ; ------------------------------------------------------------------- ConsoleWrite("Step 6: Get barcode info" & @CRLF) ConsoleWrite("Valid ID for CODE128: " & ZBarcode_ValidID(20) & @CRLF) ConsoleWrite("Barcode name for CODE128: " & ZBarcode_BarcodeName(20) & @CRLF) ConsoleWrite("Default X-dim for CODE128: " & ZBarcode_Default_Xdim(20) & " mm" & @CRLF) ConsoleWrite(@CRLF) ; ------------------------------------------------------------------- ; Step 7: UTF-8 to ECI conversion test ; ------------------------------------------------------------------- ConsoleWrite("Step 7: UTF-8 to ECI conversion test" & @CRLF) Global $sDest If ZBarcode_UTF8_To_ECI(3, "HELLO", $sDest) Then ConsoleWrite("UTF-8 to ECI conversion succeeded: " & $sDest & @CRLF) Else ConsoleWrite("UTF-8 to ECI conversion failed, error: " & @error & @CRLF) EndIf ConsoleWrite(@CRLF) ConsoleWrite(@CRLF) ; ------------------------------------------------------------------- ; Step 8: Check Zint build info ; ------------------------------------------------------------------- ConsoleWrite("Step 8: Check Zint build info" & @CRLF) ConsoleWrite("Zint No PNG support: " & ZBarcode_NoPng() & @CRLF) ConsoleWrite("Zint GS1 support: " & ZBarcode_HaveGS1SyntaxEngine() & @CRLF) ConsoleWrite("Zint Version: " & ZBarcode_Version() & @CRLF) ConsoleWrite(@CRLF) ; ------------------------------------------------------------------- ; Step 9: Clear, reset and delete symbol ; ------------------------------------------------------------------- ConsoleWrite("Step 9: Clear, reset and delete symbol" & @CRLF) ZBarcode_Clear($pSymbol) ConsoleWrite("Symbol cleared" & @CRLF) ZBarcode_Reset($pSymbol) ConsoleWrite("Symbol reset" & @CRLF) ZBarcode_Delete($pSymbol) ConsoleWrite("Symbol deleted" & @CRLF) ConsoleWrite(@CRLF) MsgBox(64, "Demo Complete", "Zint AutoIt demo test finished successfully.") Example5.au3 #AutoIt3Wrapper_UseX64=y #include "Zint.au3" ; Zint Symbol erstellen Global $pZB = ZBarcode_Create() If @error Then Exit MsgBox(16, "ERROR", "An error occured!" & @CRLF & "Error code = " & @error, 10) ; Configure Zint Symbol structure Global $t_zint_symbol = DllStructCreate($tag_zint_symbol, $pZB) With $t_zint_symbol .symbology = $BARCODE_AZTEC .input_mode = $UNICODE_MODE .scale = 10 .outfile = @ScriptDir & "\segtest.png" EndWith If FileExists($t_zint_symbol.outfile) Then FileDelete($t_zint_symbol.outfile) Global $tagSeg = "ptr source; int length; int eci" ; --- Create continuous array --- Global $iSize = (@AutoItX64 ? 16 : 12) ;size of $tagSeg Global $tContinuousArray = DllStructCreate("byte[" & $iSize * 3 & "]") ; --- Create individual zint_seg structures --- Global $tSeg1 = DllStructCreate($tagSeg, DllStructGetPtr($tContinuousArray)) Global $tSeg2 = DllStructCreate($tagSeg, DllStructGetPtr($tContinuousArray) + $iSize) Global $tSeg3 = DllStructCreate($tagSeg, DllStructGetPtr($tContinuousArray) + 2 * $iSize) ; --- Create the text data --- Global $sText1 = "Κείμενο" ; Greek Global $sText2 = "Текст" ; Cyrillic Global $sText3 = "文章" ; Chinese ; Convert to UTF-8 (or use direct string pointers if Zint.au3 supports it) Global $tText1 = DllStructCreate("char t[256]") Global $tText2 = DllStructCreate("char t[256]") Global $tText3 = DllStructCreate("char t[256]") $tText1.t = $sText1 $tText2.t = $sText2 $tText3.t = $sText3 ; --- Fill the segment structures --- $tSeg1.source = DllStructGetPtr($tText1) $tSeg1.length = 0 ; 0 = NUL-terminated $tSeg1.eci = 9 ; Greek ECI $tSeg2.source = DllStructGetPtr($tText2) $tSeg2.length = 0 $tSeg2.eci = 7 ; Cyrillic ECI $tSeg3.source = DllStructGetPtr($tText3) $tSeg3.length = 0 $tSeg3.eci = 20 ; Chinese ECI Global $iError = 0 ; --- Call ZBarcode_Encode_Segs --- If Not ZBarcode_Encode_Segs($pZB, DllStructGetPtr($tContinuousArray), 3) Then $iError = @error MsgBox(16, "ERROR", "ZBarcode_Encode_Segs returned error: " & $iError, 10) EndIf ZBarcode_Print($pZB, 0) If Not $iError Then ShellExecute($t_zint_symbol.outfile) ZBarcode_Delete($pZB) Please test and reply. Feel free to post examples here!

I compiled the Zint DLLs again and integrated the PNG static lib. You should be able to save the image now as PNG.

AutoIt v3.3.18.0 has been released - mainly a UDF release. Thanks to @jpm and the MVPs who were responsible for the majority of code in this version. Download it here. Complete list of changes: History
