Change window background color in Tab control

Yashied · April 1, 2011

Does anyone know how to get rid of it?

GUICreate('MyGUI', 300, 300)
GUISetBkColor(0xAACCFF)
GUICtrlCreateTab(20, 20, 260, 260)
GUICtrlCreateTabItem('Item1')
GUICtrlCreateTabItem('Item2')
GUICtrlCreateTabItem('')
GUISetState()

Do
Until GUIGetMsg() = -3

UEZ · April 1, 2011

I assume you have to create a label with the same color as the gui background to put on tab.

Have a look to OwnTab-UDF from funkey.

Br,

UEZ

Yashied · April 1, 2011

Thanks, but I'm interested in native solution, not a trick. I can not understand where Tab takes the background color. If I write the following

_WinAPI_SetClassLongEx($hTab, $GCL_HBRBACKGROUND, _WinAPI_CreateSolidBrush(0xFFCCAA))

still nothing happens...

Of course, I can draw your own skin or use a Windows theme, but it is quite time-consuming solution.

martin · April 1, 2011

On 4/1/2011 at 8:02 PM, 'Yashied said:
Thanks, but I'm interested in native solution, not a trick. I can not understand where Tab takes the background color. If I write the following

I thgink that the tab control uses the default windows background colour so you could change that I suppose.

Having seen the same question asked over the years and seen SmOke_N's attempts (failed) to get round it I am fairly sure you won't find a native solution. That is why Delphi (which I use) has it's own nice tab control which doesn't have all problems the windows one has.

One way to avoid the wrong color at the top left is to set the tab widths so they fill the width of the tab control. Placing a label over the offending area works quite well but you have to adjust the position of the label depending on which tab is selected to maintain a neat result. I think the windows tab control is very poor. If you try having tabs at the sides instead of the top you will conclude that the designers were about to leave to start work at Apple.

Yashied · April 3, 2011

While nothing is better not come up. Works under Windows Vista/7.

#Include <Constants.au3>
#Include <GUITab.au3>
#Include <WinAPIEx.au3>

Opt('MustDeclareVars', 1)

Global Const $STM_GETIMAGE = 0x0173
Global Const $PRF_CLIENT = 0x04

Global $hPic, $hTab, $hDll, $pDll, $hProc

GUICreate('MyGUI', 300, 300)
GUICtrlCreatePic(@ScriptDir & '\Tech.bmp', 0, 0, 300, 300, $WS_CLIPCHILDREN)
$hPic = GUICtrlGetHandle(-1)
GUICtrlCreateTab(20, 20, 262, 261, $TCS_FOCUSONBUTTONDOWN)
$hTab = GUICtrlGetHandle(-1)
GUICtrlCreateTabItem('Tab 1')
GUICtrlCreateTabItem('Tab 2')
GUICtrlCreateTabItem('Tab 3')
GUICtrlCreateTabItem('')

$hDll = DllCallbackRegister('_WinProc', 'ptr', 'hwnd;uint;wparam;lparam')
$pDll = DllCallbackGetPtr($hDll)
$hProc = _WinAPI_SetWindowLongEx($hTab, $GWL_WNDPROC, $pDll)

_WinAPI_SetParent($hTab, $hPic)

OnAutoItExitRegister('AutoItExit')

GUISetState()

Do
Until GUIGetMsg() = -3

Func _CreateClipRgn($hWnd)

    Local $tRect
    Local $Count = _GUICtrlTab_GetItemCount($hWnd)
    Local $Sel = _GUICtrlTab_GetCurSel($hWnd)
    Local $hRgn = _WinAPI_CreateRectRgn(0, 0, 0, 0)
    Local $hTmp, $Ht

    For $i = 0 To $Count - 1
        $tRect = _GUICtrlTab_GetItemRectEx($hWnd, $i)
        If $i = $Sel Then
            $hTmp = _WinAPI_CreateRectRgn(DllStructGetData($tRect, 1) - 2, DllStructGetData($tRect, 2) - 2, DllStructGetData($tRect, 3) + 2, DllStructGetData($tRect, 4))
            $Ht = DllStructGetData($tRect, 4) - DllStructGetData($tRect, 2) + 2
        Else
            If $i = $Count - 1 Then
                $hTmp = _WinAPI_CreateRectRgn(DllStructGetData($tRect, 1), DllStructGetData($tRect, 2), DllStructGetData($tRect, 3) - 2, DllStructGetData($tRect, 4))
            Else
                $hTmp = _WinAPI_CreateRectRgn(DllStructGetData($tRect, 1), DllStructGetData($tRect, 2), DllStructGetData($tRect, 3), DllStructGetData($tRect, 4))
            EndIf
        EndIf
        _WinAPI_CombineRgn($hRgn, $hRgn, $hTmp, $RGN_OR)
        _WinAPI_DeleteObject($hTmp)
    Next
    $tRect = _WinAPI_GetClientRect($hWnd)
    $hTmp = _WinAPI_CreateRectRgn(DllStructGetData($tRect, 1), DllStructGetData($tRect, 2) + $Ht, DllStructGetData($tRect, 3) - 2, DllStructGetData($tRect, 4) - 1)
    _WinAPI_CombineRgn($hRgn, $hRgn, $hTmp, $RGN_OR)
    _WinAPI_DeleteObject($hTmp)
    Return $hRgn
EndFunc   ;==>_CreateClipRgn

Func _WinProc($hWnd, $iMsg, $wParam, $lParam)
    If _WinAPI_IsThemeActive() Then
        Switch $iMsg
            Case $WM_ERASEBKGND
                Local $tRect[2]
                Local $hParent = _WinAPI_GetParent($hWnd)
                Local $hRgn = _CreateClipRgn($hWnd)
                Local $hPrev = _WinAPI_GetClipRgn($wParam)
                $tRect[0] = _WinAPI_GetWindowRect($hParent)
                $tRect[1] = _WinAPI_GetWindowRect($hWnd)
                _WinAPI_ExtSelectClipRgn($wParam, $hRgn, $RGN_DIFF)
                _WinAPI_DrawBitmap($wParam, DllStructGetData($tRect[0], 1) - DllStructGetData($tRect[1], 1), DllStructGetData($tRect[0], 2) - DllStructGetData($tRect[1], 2), _SendMessage($hParent, $STM_GETIMAGE))
                _WinAPI_SelectClipRgn($wParam, $hPrev)
                _WinAPI_DeleteObject($hRgn)
                Return 1
            Case $WM_PAINT
                Local $tPaint
                Local $hDC = _WinAPI_BeginPaint($hWnd, $tPaint)
                Local $hRgn = _CreateClipRgn($hWnd)
                _WinAPI_ExtSelectClipRgn($hDC, $hRgn, $RGN_AND)
                _WinAPI_CallWindowProc($hProc, $hWnd, $WM_PRINTCLIENT, $hDC, $PRF_CLIENT)
                _WinAPI_DeleteObject($hRgn)
                _WinAPI_EndPaint($hWnd, $tPaint)
                Return 0
        EndSwitch
    EndIf
    Return _WinAPI_CallWindowProc($hProc, $hWnd, $iMsg, $wParam, $lParam)
EndFunc   ;==>_WinProc

Func AutoItExit()
    _WinAPI_SetWindowLongEx($hTab, $GWL_WNDPROC, $hProc)
    DllCallbackFree($hDll)
EndFunc   ;==>AutoItExit


UEZ · April 3, 2011

Nice solution / workaround Yashied!

Instead using a bitmap you can create a bitmap with same color as the background.

Br,

UEZ

Yashied · April 3, 2011

Without bitmap.

#Include <Constants.au3>
#Include <GUITab.au3>
#Include <WinAPIEx.au3>

Opt('MustDeclareVars', 1)

Global Const $PRF_CLIENT = 0x04

Global $hTab, $hDll, $pDll, $hProc

GUICreate('MyGUI', 300, 300)
GUISetBkColor(0xAACCFF)
GUICtrlCreateTab(20, 20, 262, 261, $TCS_FOCUSONBUTTONDOWN)
$hTab = GUICtrlGetHandle(-1)
GUICtrlCreateTabItem('Tab 1')
GUICtrlCreateTabItem('Tab 2')
GUICtrlCreateTabItem('Tab 3')
GUICtrlCreateTabItem('')

$hDll = DllCallbackRegister('_WinProc', 'ptr', 'hwnd;uint;wparam;lparam')
$pDll = DllCallbackGetPtr($hDll)
$hProc = _WinAPI_SetWindowLongEx($hTab, $GWL_WNDPROC, $pDll)

OnAutoItExitRegister('AutoItExit')

GUISetState()

Do
Until GUIGetMsg() = -3

Func _CreateClipRgn($hWnd)

    Local $tRect
    Local $Count = _GUICtrlTab_GetItemCount($hWnd)
    Local $Sel = _GUICtrlTab_GetCurSel($hWnd)
    Local $hRgn = _WinAPI_CreateRectRgn(0, 0, 0, 0)
    Local $hTmp, $Ht

    For $i = 0 To $Count - 1
        $tRect = _GUICtrlTab_GetItemRectEx($hWnd, $i)
        If $i = $Sel Then
            $hTmp = _WinAPI_CreateRectRgn(DllStructGetData($tRect, 1) - 2, DllStructGetData($tRect, 2) - 2, DllStructGetData($tRect, 3) + 2, DllStructGetData($tRect, 4))
            $Ht = DllStructGetData($tRect, 4) - DllStructGetData($tRect, 2) + 2
        Else
            If $i = $Count - 1 Then
                $hTmp = _WinAPI_CreateRectRgn(DllStructGetData($tRect, 1), DllStructGetData($tRect, 2), DllStructGetData($tRect, 3) - 2, DllStructGetData($tRect, 4))
            Else
                $hTmp = _WinAPI_CreateRectRgn(DllStructGetData($tRect, 1), DllStructGetData($tRect, 2), DllStructGetData($tRect, 3), DllStructGetData($tRect, 4))
            EndIf
        EndIf
        _WinAPI_CombineRgn($hRgn, $hRgn, $hTmp, $RGN_OR)
        _WinAPI_DeleteObject($hTmp)
    Next
    $tRect = _WinAPI_GetClientRect($hWnd)
    $hTmp = _WinAPI_CreateRectRgn(DllStructGetData($tRect, 1), DllStructGetData($tRect, 2) + $Ht, DllStructGetData($tRect, 3) - 2, DllStructGetData($tRect, 4) - 1)
    _WinAPI_CombineRgn($hRgn, $hRgn, $hTmp, $RGN_OR)
    _WinAPI_DeleteObject($hTmp)
    Return $hRgn
EndFunc   ;==>_CreateClipRgn

Func _WinProc($hWnd, $iMsg, $wParam, $lParam)
    If _WinAPI_IsThemeActive() Then
        Switch $iMsg
            Case $WM_ERASEBKGND
                Local $hRgn = _CreateClipRgn($hWnd)
                Local $hPrev = _WinAPI_GetClipRgn($wParam)
                Local $hBrush = _WinAPI_CreateSolidBrush(0xFFCCAA)
                Local $tRect = _WinAPI_GetClientRect($hWnd)
                _WinAPI_ExtSelectClipRgn($wParam, $hRgn, $RGN_DIFF)
                _WinAPI_FillRect($wParam, DllStructGetPtr($tRect), $hBrush)
                _WinAPI_SelectClipRgn($wParam, $hPrev)
                _WinAPI_DeleteObject($hBrush)
                _WinAPI_DeleteObject($hRgn)
                Return 1
            Case $WM_PAINT
                Local $tPaint
                Local $hDC = _WinAPI_BeginPaint($hWnd, $tPaint)
                Local $hRgn = _CreateClipRgn($hWnd)
                _WinAPI_ExtSelectClipRgn($hDC, $hRgn, $RGN_AND)
                _WinAPI_CallWindowProc($hProc, $hWnd, $WM_PRINTCLIENT, $hDC, $PRF_CLIENT)
                _WinAPI_DeleteObject($hRgn)
                _WinAPI_EndPaint($hWnd, $tPaint)
                Return 0
        EndSwitch
    EndIf
    Return _WinAPI_CallWindowProc($hProc, $hWnd, $iMsg, $wParam, $lParam)
EndFunc   ;==>_WinProc

Func AutoItExit()
    _WinAPI_SetWindowLongEx($hTab, $GWL_WNDPROC, $hProc)
    DllCallbackFree($hDll)
EndFunc   ;==>AutoItExit

UEZ · April 3, 2011

I need these includes

#include <Constants.au3>
#include <GuiTab.au3>
#include <TabConstants.au3>
#include <WinAPIEx.au3>
#include <WindowsConstants.au3>

and have to add Local Const $WM_PRINTCLIENT = 0x0318 to _WinProc() functions!

Nice, nice, nice!

Br,

UEZ

Yashied · April 3, 2011

On 4/3/2011 at 3:13 PM, 'UEZ said:
I need these includes

You have an old version WinAPIEx.

martin · April 3, 2011

It's brilliant Yashied. I like it a lot

Since a solution to this has been asked so often I think you should put it in example scripts.

taietel · April 3, 2011

Wonderful. Thanks Yashied (also for this)! As Martin said you should put it in example scripts.

Yashied · April 3, 2011

Unfortunately, in XP will need to create a slightly different clip region (rounded corners). Also, it may depend on the used Windows theme.

Edited April 3, 2011 by Yashied

AdmiralAlkex · April 5, 2011

On 4/3/2011 at 11:16 PM, 'Yashied said:
Unfortunately, in XP will need to create a slightly different clip region (rounded corners). Also, it may depend on the used Windows theme.

You mean that one pixel in the corner? I would think the 1 pixel wide space between tabs is worse.

Also when you disable theming the color overflow the tab.

Screenshots

LeviStevens · July 11, 2013

I do not have the WinAPIEx.au3 in my install. Where can I find this to use this example? Trying to over come this issue where I am using custom colors and I don't want the default grey theme.

I've tried painting a colored label, but then the tabs (button style) aren't visible until you click on them (example, below).

GUICtrlCreateLabel("", 0, 120, 751, 320)
GUICtrlSetBkColor(-1, $iContentArea)
GUICtrlSetState(-1, $GUI_DISABLE)

LeviStevens · July 12, 2013

Maybe someone could figure out how to implement this API in a UDF to accomplish the colors?

http://support.microsoft.com/kb/179909

Melba23 · July 12, 2013

LeviStevens,

The WinAPIEx UDF is included with the 3.3.9.x Beta installs. I suggest you download one of them.

But I use something like this to produce coloured tabs:

#include <GuiConstantsEx.au3>
#include <GuiTab.au3>
#include <StaticConstants.au3>

; Tab colours
Global $aTabColours[4] = [0xFFC0C0, 0xC0FFC0, 0xC0C0FF, 0xC0C0C0]

; Create GUI
Global $hGUI = GUICreate ("Test", 400,300)
GUISetBkColor (0)

; Create label to cover tab "tab"
Global $hColourTab = GUICtrlCreateLabel("", 0, 0, 1, 1, BitOR($SS_NOTIFY, $SS_CENTER, $SS_SUNKEN))

; Create tab
Global $hTab = GUICtrlCreateTab(5, 5,390, 290)
Global $hTab_Handle = GUICtrlGetHandle($hTab)

; Create tab items and colour them
For $i = 0 To 3
    GUICtrlCreateTabItem ("Tab item - " & $i)
    _GUICtrlTab_SetBkColor($hGUI, $hTab, $aTabColours[$i])
    GUICtrlCreateTabItem ("")
Next

_GUICtrlTab_SetCurSel($hTab_Handle,0)
_GUICtrlTab_SetCurFocus($hTab_Handle,0)
TabEvent()

GUISetState ()

While 1
    Switch GUIGetMsg ()
        Case $GUI_EVENT_CLOSE
            Exit
        Case $hTab
            TabEvent()
    EndSwitch
WEnd

Func TabEvent()

    ; Set values
    Local $iTab_X = 5, $iTab_Y = 5, $iTab_Margin = 1
    ; Get index of current tab
    Local $iTab_Index = GUICtrlRead($hTab)
    ; Get coordinates of TabItem
    Local $aTab_Coord = _GUICtrlTab_GetItemRect($hTab_Handle, $iTab_Index)
    ; Get text of TabItem
    Local $sTab_Text = _GUICtrlTab_GetItemText($hTab_Handle, $iTab_Index)
    ; Place label
    GUICtrlSetPos($hColourTab, $iTab_X + $aTab_Coord[0] + $iTab_Margin, $iTab_Y + $aTab_Coord[1] + $iTab_Margin, $aTab_Coord[2] - $aTab_Coord[0] - ($iTab_Margin * 2), $aTab_Coord[3] - $aTab_Coord[1] - ($iTab_Margin * 2) + 5)
    ; Set text
    GUICtrlSetData($hColourTab, $sTab_Text)
    ; Set colour
    GUICtrlsetBkColor ($hColourTab,$aTabColours[$iTab_Index] )
    ; Set focus
    _GUICtrlTab_SetCurFocus($hTab_Handle,$iTab_Index)

EndFunc

Func _GUICtrlTab_SetBkColor($hWnd, $hSysTab32, $sBkColor)

    ; Get tab position
    Local $aTabPos = ControlGetPos($hWnd, "", $hSysTab32)
    ; Get size of user area
    Local $aTab_Rect = _GUICtrlTab_GetItemRect($hSysTab32, -1)
    ; Create label
    GUICtrlCreateLabel("", $aTabPos[0] + 2, $aTabPos[1] + $aTab_Rect[3] + 4, $aTabPos[2] - 6, $aTabPos[3] - $aTab_Rect[3] - 7)
    ; Colour label
    GUICtrlSetBkColor(-1, $sBkColor)
    ; Disable label
    GUICtrlSetState(-1, $GUI_DISABLE)

EndFunc   ;==>_GUICtrlTab_SetBkColor

Any use?

M23

JakeJohnson74 · April 2, 2015

When I run this, it does not repaint the controls I place inside of the tab control.

For example a listview, the columns are not visible - once I mouse over them they are painted.

What can I do to make this behave normally?

Melba23 · April 2, 2015

JakeJohnson74,

Works fine for me:

#include <GuiConstantsEx.au3>
#include <GuiTab.au3>
#include <StaticConstants.au3>

; Tab colours
Global $aTabColours[4] = [0xFFC0C0, 0xC0FFC0, 0xC0C0FF, 0xC0C0C0]

; Create GUI
Global $hGUI = GUICreate ("Test", 500, 500)

; Create label to cover tab "tab"
Global $hColourTab = GUICtrlCreateLabel("", 0, 0, 1, 1, BitOR($SS_NOTIFY, $SS_CENTER, $SS_SUNKEN))

; Create tab
Global $hTab = GUICtrlCreateTab(10, 10, 400, 300)
Global $hTab_Handle = GUICtrlGetHandle($hTab)

; Create tab items and colour them
For $i = 0 To 3
    GUICtrlCreateTabItem ("Tab item - " & $i)
    _GUICtrlTab_SetBkColor($hGUI, $hTab, $aTabColours[$i]) ; Are you creating the coloured background first? <<<<<<<<<<<<<<<<<<<
    GUICtrlCreateButton("Button " & $i, 50 + (80 * $i), 50, 80, 30)
    GUICtrlCreateListView("Col " & $i, 50, 100, 200, 100)
    GUICtrlCreateTabItem ("")
Next

_GUICtrlTab_SetCurSel($hTab_Handle,0)
_GUICtrlTab_SetCurFocus($hTab_Handle,0)
TabEvent()

GUISetState ()

While 1
    Switch GUIGetMsg ()
        Case $GUI_EVENT_CLOSE
            Exit
        Case $hTab
            TabEvent()
    EndSwitch
WEnd

Func TabEvent()

    ; Set values
    Local $iTab_X = 10, $iTab_Y = 10, $iTab_Margin = 1
    ; Get index of current tab
    Local $iTab_Index = GUICtrlRead($hTab)
    ; Get coordinates of TabItem
    Local $aTab_Coord = _GUICtrlTab_GetItemRect($hTab_Handle, $iTab_Index)
    ; Get text of TabItem
    Local $sTab_Text = _GUICtrlTab_GetItemText($hTab_Handle, $iTab_Index)
    ; Place label
    GUICtrlSetPos($hColourTab, $iTab_X + $aTab_Coord[0] + $iTab_Margin, $iTab_Y + $aTab_Coord[1] + $iTab_Margin, $aTab_Coord[2] - $aTab_Coord[0] - ($iTab_Margin * 2), $aTab_Coord[3] - $aTab_Coord[1] - ($iTab_Margin * 2) + 5)
    ; Set text
    GUICtrlSetData($hColourTab, $sTab_Text)
    ; Set colour
    GUICtrlsetBkColor ($hColourTab,$aTabColours[$iTab_Index] )
    ; Set focus
    _GUICtrlTab_SetCurFocus($hTab_Handle,$iTab_Index)

EndFunc

Func _GUICtrlTab_SetBkColor($hWnd, $hSysTab32, $sBkColor)

    ; Get tab position
    Local $aTabPos = ControlGetPos($hWnd, "", $hSysTab32)
    ; Get size of user area
    Local $aTab_Rect = _GUICtrlTab_GetItemRect($hSysTab32, -1)
    ; Create label
    GUICtrlCreateLabel("", $aTabPos[0] + 2, $aTabPos[1] + $aTab_Rect[3] + 4, $aTabPos[2] - 6, $aTabPos[3] - $aTab_Rect[3] - 7)
    ; Colour label
    GUICtrlSetBkColor(-1, $sBkColor)
    ; Disable label
    GUICtrlSetState(-1, $GUI_DISABLE)

EndFunc   ;==>_GUICtrlTab_SetBkColor

M23 Edited April 2, 2015 by Melba23
Wrong button too soon!

JakeJohnson74 · April 2, 2015

@Melba

Haha it would probably help if I referenced the code I was talking about! haha Sorry

It was Yashied's example. Yours does, in fact, work fine. Actually... I think I might just use that instead! It will just take a little cannibalizing because I only need just the area to the right of the tabs.

Edited April 2, 2015 by JakeJohnson74

Melba23 · April 2, 2015

JakeJohnson74,

No probs.

M23

Sign In

Change window background color in Tab control

Recommended Posts

Yashied

UEZ

Yashied

martin

Yashied

UEZ

Yashied

UEZ

Yashied

martin

taietel

Yashied

AdmiralAlkex

LeviStevens

LeviStevens

Melba23

JakeJohnson74

Melba23

JakeJohnson74

Melba23

Create an account or sign in to comment

Create an account

Sign in

Recently Browsing 0 members

Browse

AutoIt Resources

Release

Beta
